Showing 25 of 962 matching Reactors.
UNUSED
Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated, and "U" stamped.
welded dish heads (2:1) 12 mm thick
Coil: 114 mm OD x 4 mm thick,
Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm). Coil heating surface area.
With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug.
20" Manhole with Cover and davit arm assist, one 6" sight glass, Support Type: Lugs.
MFR # 12269 Model SA-3000 Special three top lifting lugs, six leg couplings, four side wall lugs Shell=1 & 1/64", heads=1 & 1/64", jacket =5/8" PTE size 10 drive with an EX proof 20 HP motor and a dry seal. 36" main cover. 18" man way with pro ring and sight glass assembly with man way assist.
6,300 liter order number 60669 Pressure ratings: Internal -1/6 Bar @ -25/+200°C total volume 8,190 liters; Jacket rated -1/6 Bar @ -25/+200°C total volume 795 liters. Lined with glass WWG9115 With a top mounted drive with Burgmann mechanical seal type M462L-D20 and Burgmann Thermosyphon TS 2000 pneumatic bottom outlet valve, and solids dosing device,
jacketed high pressure reactor Jacket volume: 1700 liter Total length: 8000 mm Jacket wall thickness: 30 mm
Auft # 37387 belt driven by LOHER 3.6 KW, 1715 RPM, 3/7.7-13.3A/60Hz/220-380 volt motor, ex proof (T3). Designed to German TUV standards. Reglassed in Romani by UGE 2001.
Shell rated 150/FV @ 450 degrees F. Conventional jacket 150/FV @ 450 degrees F with welded 2:1 elliptical heads Alloy mixer with dual tier agitation, lower is a CBT, upper is a PBT
Drive Motor is CE certified
Dual Rated Vessel
Dual rated vessel 70/FV psi @ -40 F to 450 F
Jacket 47/47 w/FV psi @ -40 F to 450 F
R-0203 Built 2017 Motor EX proof & VFD compatible
Used reactors play a vital role in manufacturing environments where control over chemical, thermal, or biological reactions is essential. Whether you’re scaling up active pharmaceutical ingredients, processing specialty chemicals, or conducting precision fermentation, IPP offers ready-to-ship reactors from 20 global plant sites. With more than 47 years of expertise, IPP maintains the world’s largest inventory of secondhand and surplus process equipment.
IPP stocks jacketed, glass-lined via its group company Universal Glasteel Equipment (UGE), pressure-rated, and sanitary reactors in a range of capacities and configurations. All systems are professionally inspected and available immediately for fast global delivery.
