Showing 25 of 164 matching Basket Centrifuges.
top load, bottom discharge,
12mm thick basket,
3.15 square meter filter area,
1100 rpm permissible speed
single motion plow driven by a hydraulic powerpack, powerpack driven by approx 0.75kw EX motor, mounted on a steel baseplate,
clarifier basket centrifuge
bottom discharge
(2) horizontal baffles
basket capacity 7.6 cu ft.
316SS basket, curb and plow
Top driven by hydraulic powerpak
Hinged access port
1" rotary pneumatic skimmer
basket only
1/4 " drainage holes
Eight 7/8" bolt hole pattern
spare
top and bottom section
bottom discharge basket centrifuge
bottom discharge design
with single action pneumatic operated plow cylinder.(no Plow)
Cover has an inspection door with a 9" sight glass
Cover has the following openings for piping connections
One, 6" weld neck flange,
One 2" opening for feed pipe,
Three, 1" opening for accessories.
Ferrum basket centrifuge
with Titus cyclone cake discharge system
Complete centrifuge
and discharge system is gas-tight design.
deep perforated basket
pressure rated 1.96 Sqm, 0 to 950 upm
480 kg,
316L s/steel housing and cover
pressure rated 1.6 bar @ 120 degrees C
Top cover has 100mm sightglass with light
225mm sightglass
75mm wash pipe
75mm feed pipe
45mm, 80mm, and a 1/2 hinged cover
150mm filtrate outlet
Unit has top entering feed and wash pipes
and has a hydraulic knife for cake removal from basket walls
Cake is pneumatically removed from the centrifuge
though a Krauss Maffei,
Titan cyclone dryer,
which pulls the cake out through the top of the centrifuge
Complete system includes a 630 liter SS horizontal mother liquor tank manufactured by Edak,
Serial number 965/1,
rated 1.6 bar,
Krauss Maffei solvent condensor manufactured by J Engelsman, Serial Number 15641/2,
miscellanous centrifugal pumps,
K-M Titus cylone discharge system with 2,880 CuM/Hr,
SS suction fan driven by a 30 KW,
3 phase 50 cycle EExeII motor,
385 liter 1.4571 SS cake cyclone,
692 mm diameter x 450 mm ss with 1100 mm cone,
discharging the cake into a 500 liter 1.4435 SS jacketed product receiver,
manufactured by Hanag, rated -1/2 bar @ -30 to 200 degrees C internal;
6 bar @ -30 to 200 degrees C in the 1/2 pipe coil jacket,
with bolted dished top, cone bottom,
1/2 pipe coil jacket on cone bottom,
1000mm diameter x 342 mm straight side with 682 mm deep cone bottom.
Entire system is sealed and designed for use in Solvent processes.
Previous use allowed solvent ladened product cake to be dried using ambient temperature in the cyclone air flow before being collected in the product bin
perforated basket centrifuge
316SS TI (1.4571)
Half top hydraulically operated liftable cover
Basket thickness 10mm
Hydraulic operated knife.
W/hydraulic powerpak, mfd by Hydramatic.
Hydraulic driver Type A2P
W/250mm sight glass
perforated basket centrifuge,
Top load/bottom discharge design.
Hinged half moon shaped top cover,
cover 837mm long x 431mm wide.
stainless steel manaul 2-motion plow.
Openings: feed pipe 85mm, filtrate 2-80mm,
solids 2-710mm x 100mm wide curved outlets,
sight glasses: 1-215mm,
1-125mm, 1-50mm.
vertical decanter centrifuge
with motorized liquid skimmer
Rated 150/180 l/mn flow rate
manufactured by Rousselet Robatel
Rated 150/180 l/mn flow rate
5-60 degrees C
100 liter solids capacity
Solid bowl is 1000mm diameter x 500 mm deep bowl
1.4539 Stainless top cover
mounted on a hinge
with an electric motor for opening the cover
liquid skimmers
and solid discharge skimmer
Liquid skimmer is driven by a 0,15/0,22kW, 3 ph/50 cyc/ 400 volt electrical motor, manufactured by CEO, type 63-2/4,
serial number 00017320102, 2 speed
1400/2760 rpm
Includes (1) control panel;
with (1) control cabinet
with hydraulic power pack with aa 0,55-0,66kW electrical motor, manufactured by Leroy Somer, type LS80LT, serial number 660550RM001, 3ph/50-60Hz/230-460V/ 1.385-1.700rpm; Centrifuge and powerpack is mounted on stainless steel frame. System is CE rated
DeLaval Mark III
btm discharge perforated basket centrifuge.
(2) horiz baffles.
Single motion pneumatic plow.
1" rotary pneumatic skimmer.
Max cake thickness 4.5"
Feed pipe 1 1/2",
filtrate outlet 4",
solids outlet 21".
Dynapower hydraulic motor. (*) (Not to be used for any drug or food application).
perforated basket centrifuge
EX motor with air cooling fan mounted on top
driven by 0.12 KW 3/50/380 volt motor.
NO MOTOR. Heine 316SS (V4AE)Basket thickness 6mmPneumatic operated liftable half top cover.W/1-200mm sight glass, 1-100mm sight glass, 2-25mm, 1-50mm, 1-75mm; 1-100mm discharge, W/hydraulic powerpack
top load, bottom discharge
wall thickness of the basket 12mm
lid with assist mechanism
basket with electric motor
sanitary perforated basket centrifuge
140 kg wet material
with handbrake
openings: 2-75mm feed pipes, 1-75mm filtrate outlet, 2-75mm sightglasses
bottom discharge perforate basket centrifuge
Single motion pneumatic operated plow
9 cu ft cake capacity
Variable frequency drive provided after sale
batch perforated
Cake capacity 140mm
Basket and curb material Hastelloy C-4 (2.4610)
Openings: 1-40mm feed with cone, 1-25mm wash pipe with (2) spray nozzles, 1-50mm vapour, 1-100mm filtrate, 1-175mm, 1-75mm sight glasses,
hinged lid with pneumatic assist.
perforated basket centrifuge.
Hastelloy basket,
halar lined curb,
2.4610 basket,
cover 1.4571 material
Gas tight
Cover 1/2 leftable hydraulically.
Control panel.
Perforation 8mm dia
W/0.75 KW,
Motor: 3 phase
Hydraulic pump: 0.75 KW, 3/50/380 volt, 1450 rpm
btm discharge perforate basket centrifuge
Pneumatic single motion plow
Hydreco hydraulic motor
6 cu in/rev
bottom discharge basket centrifuge.
Single motion pneumatic plow
AC drive supplied after sale.
1.4581 perforated basket centrifuge.
Half top hydraulically operated liftable cover.
Basket thickness 10mm
Hydraulic operated knife.
mfd by Hydramatic,
hydraulic driver Type A2P.
W/250mm sight glass
perforated basket centrifuge
Material of construction V4AE.
5mm wall thickness
Openings: 1-1" feed, 1-1 1/2" vapour, 1-3" filtrate,
top cover: 2-4" sight glasses, 2-1".
When your process demands efficient separation of solids from liquids, basket centrifuges offer reliable, high-speed solutions across a wide range of industries. With more than 47 years of process equipment expertise, IPP delivers immediate access to used basket centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used basket centrifuges from IPP helps companies minimize capital expenditures while securing proven, production-ready equipment.
Basket centrifuges operate by spinning a perforated basket at high speeds, using centrifugal force to separate solids from liquids. They are essential for batch and continuous separation processes in industries ranging from pharmaceuticals to wastewater treatment. Their design allows for efficient handling of a wide variety of slurries, pastes, and particulate-laden liquids.
Basket centrifuges are engineered to endure tough processing conditions while maintaining product purity:
High centrifugal forces for rapid and thorough separation
Perforated or imperforated basket options for different process needs
Designs for manual, semi-automatic, or fully automatic operation
Adaptable for batch or continuous processing
Easy disassembly for cleaning, inspection, and maintenance
