Conveyors, Bins, Tanks, and more

• design pressure 0.17/3.5 bar @ -15/100 degrees C,
• design code: ASME VIII DIV 1 (latest)

(1) 10 m3/hr @ 35m head 316 stainless steel centrifugal pump, manufactured by CP Pumpen Ag, serial #06-00784/51642, type MKP 40-25-160, pressure 16 bar @ -30/200 degrees C, differential pressure 5.5 bar, NPSH 1.2m, driven by 5.5kw 3/50/400 volt 2911 rpm IP65 Eex de IIBT4 ATEX motor, magnetic drive, openings suction 32mm, discharge 25mm, mounted on a baseplate

• 6300 liter working volume
• CE6300 series,
• design pressure -1/3.5 bar @ -25/170 degrees C (7575 liter),
• glass type 3009U,
• design code: AD-M 2000, CAT IV, 97/23/EC,

fork liftable product tote bin

#4 inside with welds ground and polished
Lifting eyes on top of the tank
3” Tri- Clamp connections
Insulation - 1” cork with mild steel insulation

• Rated for lethal service.
• Nozzles with Inconel 625 inlay.
• Glasslined beavertail baffle with WIKA TR-10 & PT100 temperature probes.
• Mechanically sealed agitator: FlowServe MD-200 DN140.
• See sales comments for additional options.

• Sanitary Insulation Shroud

• 10000 liter working capacity,
• design pressure internal 3.5 bar + full vacuum @ 100 degrees C (10820 liter),
• internally highly polished to 0.5 to 0.8 microns,
• design code: BS5500 1997 CAT 2
• top platform and vertical ladder available if required

• Polished Standards: CODAP 90with (2) stainless steel handles on side wall to moving the tank.

• design pressure 1.030/3.5 bar @ -15/100 degrees C,
• design code ASME VIII DIV. 1. 1989 (DEC 90 ADDENDA)

With (2) PTFE lined centrifugal pumps, manufactured by Richter Chemie, type PCK/F 32-160, 2900 rpm, 165mm diameter impellor, mounted on a base plate,

Rated 2000 lbs./Hr. at 40 lbs./Cu.Ft. Two-(2) 5' 9 &3/8 cooling sections. Rotation: Clockwise.

• working capacity 1600 liter
• design pressure internal 3.5 bar + full vacuum @ -25/170 degrees C,
• design code: PD5500-2000-MODULE G-GAS GROUP 1

• 316L stainless steel electro highly polished inside/outside hopper,
• pressure -0.5/0.5 bar @ 100 degrees C,
• pneumatic actuated valve on bottom discharge,
• hopper with a 316L electro polished 98 liter stainless steel PTS 400-C (powder transfer system), serial #PTS-4587, pressure -1/3 bar @ 100 degrees C,
• design code PED group 2, Cat 1, Module A,
• with (2) filters

Repaired by Alfonso
Serial Number 9138-86
(3) reinforcing rings around straight side of tank

• Built to BS 5500:1994 code.

• design pressure internal 3.5 bar + full vacuum @ -25/185 degrees C,
• jacket 6 bar + full vacuum @ -25/185 degrees C,
• design code BS5500 1991 CAT 2,

With 316L stainless steel centrifugal pump, driven by 5.5kW, 3/50/415 volt, 2900 rpm Ex IP55 motor, mechanical seal with lubricator pot, mounted on a baseplate,

• Caster-mounted portable mixing tank.
• With handles mounted on tank straight side.

• open topped with lids
• weld flat sloping bottom

• Full Mirror Polish, sanitary construction with insulation shroud.
• Half pipe coil jacket.
• 10 wraps half pipe coil jacket counted as stiffening rings. Sanitary Contruction: Yes. Support: Feet.

• With flame arrestors.

Accurate Dry Feeder
Tuf-Flex volumetric series 600
with Vinyl Flex hopper
18" ID x 18" ID x 12" deep
with a 48" long 304SS tube
Unit has (2) 1/4 HP Pacific Scientific Motors, 1800 RPM, 90 DC volts
One moter controls feed rate, second motor for hopper agitation. Mounted on a portable cart with wheels, Power cord and plug. Agitation and Feed rate control boxes mounted under the feeder
All electricals are Class I Group D enclosures
28" wide (without screw)

• pressure internal 3.5 bar + full vacuum @ -25/170 degrees C,
• design code BS5500 1991 CAT 2,

With 316L stainless steel centrifugal pump, mechanical seal with lubricator pot, driven by 5.5kW, 3/50/415 volt 2900 rpm EEx de IIB T4 IP55 motor, mounted on a baseplate,

• design pressure -1.030/3.5 bar @ -15/100 degrees C,
• design code ASME VIII DIV 1 1989 (DEC 90 ADDENDA),

(2) 25m3/hr @ 11.8m head PTFE lined centrifugal pumps manufactured by CP Pumpen AG, type MKPL 80-50-200, 196mm diameter impellor, 1450 rpm, 20/30 degrees C, CE Ex II 2GD T1-T4 classification, mounted on a baseplate,

• With liquid level sight glass on side.

volumetric feeder
10 amp. With SS hopper
Mounted on a stand with wheels.
ontrols for Stop & Start filling cycle, fill quanity with precision counter that controls the amount of product dispensed and the batch size.The speed of the auger is regulated by a seperate control.
