Showing 25 of 725 matching Shell and Tube Heat Exchangers.
tube pressure rated by -1/10bar @-10/200 degrees C (volume 66 liter), shell pressure rated by -1/10bar @ -10/200 degrees C (volume 180 liter). Tubes alpha silicon carbide. Length: 4,787 mm. Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 121. Tube Diameter: 14 mm. Tube Length: 4,200 mm. Tube Thickness: 1.5 mm. Nozzle Schedule: shell side: (1) DN100, (2) DN200, (1) DN300; tube side: (1) DN150, (1) DN200. Capacity: 246 L. Heat Exchanger Tube Capacity: 66 L.
Rated FV/300 psi @ -20 to 425 degrees tube side; FV/50 psi @ -20 to 425 degrees F shell side.
with glass lined clamped heads Tube Number: 18. Tube Diameter: 0.75 in. Tube Length: 216 in.
AL6XN channel heads
with R-Stamp(1994) Tube Diameter: 1.25 in. Tube Length: 144 in. Tube Thickness: 0.02 in. Nozzle Schedule: - Nozzle Schedule: - Two 32" tube side nozzles (brine inlet & outlet) - One 18" steam inlet - One 4" condensate outlet - One 3" drain - Two 1" drain/vents.
Type BEM.
Replacement shell, spare, no heads with the unit. Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 135. Tube Diameter: 0.75 in. Tube Length: 141 in. Tube Thickness: 0.08 mm. Nozzle Schedule: 3" outlet, 10" inlet, (2) 3/4", 3/4" vent, 3/4" drain..
Head coating: Ceramic coating glass lined
Shell: 60 PSI @ 350 degrees F
Tube: 60 PSI @ 350 degrees F
Total volume: tube side 1600 liter; shell side 960 liter.
(2) flat heads
Single pass Tube Number: 10. Tube Diameter: 1 in. Nozzle Schedule: Openings: tubeside 2-14"; shell 1-6", 1-1 1/2", 2-1" spring assisted bolts. .
design pressure tube side 29.31 barg @ 251.7 degrees C (425 psi at 495 degrees F), shell side 12.07 barg @ 212.8 degrees C (175 psi at 415 degrees F)
Shell : expansion joint
(1) titanium bonnet head, (1) titanium dished head Tube-side Passes: 1. Tube Number: 1,450. Tube Diameter: 19 mm. Tube Length: 4,872 mm. Nozzle Schedule: openings tubeside: 1 head with 1-280mm, 2-15mm, 1 head with 1-290mm with a 38mm off shoot, shell side: 1-425mm, 1-320mm, 1-25mm.
polytube graphilor heat exchanger
Tube sheets Face to face is 23' 9"
(2) 316Ti (1.4571) stainless steel dished heads,
Insulation: Fully insulated
Certification: TUV certified
pressure tubeside 4 bar @ 50 degrees C (35 liter), shell 0.5 bar @ 120 degrees C (69 liter) Tube Number: 92. Tube Diameter: 18 mm. Tube Length: 1,250 mm. Nozzle Schedule: - Tubeside openings: (1) head with 2-50mm, (1) head with no openings - Shell openings: 2-100mm, 1-25mm.
(2) 316Ti (1.4571) stainless steel bonnet heads
Insulation: Fully insulated
Certification: TUV certified
pressure tubeside 0.5 bar @ 120 degrees C (38 liter), shell 5 bar @ 120 degrees C (29 liter) Tube Number: 48. Tube Diameter: 18.8 mm. Tube Length: 1,250 mm. Nozzle Schedule: Tube side openings: (1) head with 1-100mm, (1) head with 1-100mm - Shell openings: 2-25mm.
pressure tube side 8 barg @ 250 degrees C (780 liter)
shell 15 barg @ 250 degrees C (610 liter)
Certification: TUV
pressure tube side 8 barg @ 250 degrees C (1335 liter)
shell 15 barg @ 250 degrees C (900 liter)
Volume (tube side): 1335 liters
Volume (shell side): 900 liters
(1) carbon steel bonnet head,
(1) carbon steel dished head Tube-side Passes: 1. Tube Number: 618. Tube Diameter: 25 mm. Tube Length: 3,000 mm. Tube Thickness: 2 mm.
4.0/2,8 Sqm
no heads
pressure tube side -1/6 bar @ 200 deg C
volume 815 liter
shell side -1/6 bar @ 200 deg C
volume 1560 liter Tube Length: 2,496 mm. Tube Thickness: 2 mm. Nozzle Schedule: - Openings (shell): 1-500mm, 1-150mm, 2-200mm, 2-15mm.
Rated 150/FV @ -20 to 400 degrees F tube side
150/FV @ -20 to 400 degrees F Shell Side
Unit has (2) bolted flat heads
(1) Tanalum, (1) CS with tantalum lining Length: 94.5 in. Tube Number: 84. Tube Diameter: 0.75 in. Tube Length: 72 in. Nozzle Schedule: - Nozzles: Shell side has two 4" nozzles with 1" reducing flanges - Inlet/outlet: Tube side inlet is 4", tube side outlet is 3" with a 1" drain..
304 SS with Hastelloy C clad tube sheet
Hastelloy lined CS shell
20" diameter x 58" face to face, overall length is 89" long Length: 58 in. Tube Type: Straight Tube. Tube Number: 325. Tube Diameter: 0.75 in. Tube Length: 58 in. Tube Thickness: 0.03 in.
Expansion bellows: Yes
(1) 321 stainless steel (1.4541) top bonnet head,
(1) 321 stainless steel (1.4541) bottom dished head, Tube-side Passes: 1. Tube Number: 181. Tube Diameter: 25 mm. Tube Length: 4,000 mm.
(1) Duplex stainless steel (1.4462) hemispherical head, (1) duplex stainless steel (1.4462) dished head
pressure tube side: -1/6 bar @ 250 deg C (815 liter), shell side: -1/6 bar @ 250deg C (1560 liter) Tube Diameter: 25 mm. Tube Length: 2,500 mm. Tube Thickness: 2 mm. Nozzle Schedule: openings: shell: 1-600mm, 2-200mm, 1-150mm, 2-20mm, 2-15mm, top head (hemespherical head ): 1-500mm, 1-50mm, bottom head (dished head): 1-300mm, 2-50mm.
Bimetallic SB111CDA706 (85% CU) over 304 SS tubes Tube-side Passes: 2. Tube Type: Straight Tube. Tube Number: 48. Tube Diameter: 0.62 in. Tube Length: 144 in. Tube Thickness: 0.04 in. Nozzle Schedule: - Shell Nozzles: Two 3" - Tube Nozzles: Two 1".
working pressure on both sides 5mm hg absolute (0.09 psi) @ 200 degrees C Tube Number: 80. Tube Diameter: 28 mm. Tube Length: 5,181 mm. Nozzle Schedule: - Openings: Tubeside - 2-75mm, Shell - 1-400mm, 1-300mm, 2-50mm (with sump) .
4-pass
fully insulated and clad Tube Type: U-Tube. Tube Number: 56. Tube Diameter: 19 mm. Tube Length: 3,956 mm. Nozzle Schedule: 2-50mm openings, shell with 2-50mm openings.
Used heat exchangers are essential in virtually every industrial setting where fluids need to be heated or cooled efficiently. These systems transfer thermal energy between liquids, gases, or steam without mixing the media—making them critical in process optimization, energy recovery and environmental control. With over 47 years of experience, IPP supplies used, secondhand and surplus heat exchangers from 20 global plant sites and maintains a massive inventory of 15,000+ systems ready for fast shipment.
IPP offers a wide variety of heat exchanger types including shell and tube, plate, air-cooled, spiral, and double-pipe designs from trusted brands like Alfa Laval, API Schmidt-Bretten, Tranter, Graham and ITT Standard.
Heat exchangers are unfired heat transfer equipment used in process plants. Heat exchangers are used for the transfer of heat or cold between two fluids for the purpose of heating the process, cooling the process, or condensing vapors during the process. Heat exchangers are measured in Square Feet. There are several different types of heat exchangers. These include:
Heat exchangers must withstand temperature, pressure and chemical exposure:
Learn more about industrial heat exchanger design and selection from Chemical Processing.
Search the IPP inventory or contact IPP’s thermal systems experts to find the right used, surplus or secondhand heat exchanger for your facility. From simple replacements to full energy recovery systems, IPP helps you optimize performance while cutting lead times and costs.
