With a Lightnin Right angle mixer , model 34-C-15, serial # 968835904301 Ratio 25.7,Out put rpm 68, 15 HP recommended. See sales comments regarding Jacket Driven by an AC motor
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pemco
Condition: Used
Material: Stainless Steel 316
Clad: Yes
Capacity (Design): 7,571 L (2,000 gallons)
Internal Pressure: 41.4 bar (600 psi)
Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 1,981 mm (78 in). Straight Side Length: 1,829 mm (72 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Brown Hutchinson, Inc.
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 1,041 L (275 gallons)
Internal Pressure: 3.4 bar (50 psi)
Internal Full Vacuum: Yes. Jacket Pressure: 3.4 bar (50 psi). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 812.8 mm (32 in). Straight Side Length: 1,930 mm (76 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Gaston County
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 5,678 L (1,500 gallons)
Internal Pressure: 3.4 bar (50 psi)
With Top mounted Philadelphia mixer, model PTE08, 30 to 1 ratio,
Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 3.4 bar (50 psi). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Diameter: 1,524 mm (60 in). Straight Side Length: 3,200 mm (126 in). Support Type: Legs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Modern Welding
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 5,678 L (1,500 gallons)
Internal Pressure: 3.4 bar (50 psi)
Jacketed on bottom 1/3 of tank. 78" diameter x 6' tangent to tangent, 3/8" side wal.
Internal Full Vacuum: Yes. Internal Temperature: 93.3 °C (200 °F). Jacket Pressure: 2.8 bar (40 psi). Jacket Temperature: 93.3 °C (200 °F). Agitation: Yes. Diameter: 1,981 mm (78 in). Straight Side Length: 1,829 mm (72 in). Support Type: Legs.
