1,000 mm (39.4 in) Stainless Steel 316 Auto Discharge-Bottom Centrifuge-Basket For Sale - IPP# 208274

Type: Centrifuge-Basket

Subtype: Auto Discharge-Bottom

Manufacturer: Ellerwerk

Model: 736U-A

Condition: Used

Material: Stainless Steel 316

Basket Diameter: 1,250 mm (49.2 in)

Basket Depth: 800 mm (31.5 in)

top load, bottom discharge, 12mm thick basket, 3.15 square meter filter area, 1100 rpm permissible speed single motion plow driven by a hydraulic powerpack, powerpack driven by approx 0.75kw EX motor, mounted on a steel baseplate,

Filtration Area: 3.2 m² (33.9 ft²). Motor Power: 40 kW (53.6 HP). Speed-RPM Maximum: 1,110. Load Weight: 550 kg (1,213 lb). Gas Tight: Yes.

Type: Centrifuge-Basket

Subtype: Auto Discharge-Bottom

Manufacturer: Ellerwerk

Model: 736 UA

Condition: Used

Material: Stainless Steel Other

Basket Diameter: 1,250 mm (49.2 in)

Basket Depth: 500 mm (19.7 in)

wall thickness of the basket 14 mm holes 8 mm with 50 mm distance Top load, cake is discharged with a small peeler that scrapes the cake from the side walls and Auto bottom discharge

Filtration Area: 1.96 m² (21.1 ft²). Speed-RPM Maximum: 950. Load Weight: 400 kg (881.8 lb).

Type: Centrifuge-Basket

Subtype: Auto Discharge-Bottom

Manufacturer: Ellerwerk

Model: 736-U-A

Condition: Used

Material: Stainless Steel Austenitic

Basket Diameter: 1,250 mm (49.2 in)

Basket Depth: 600 mm (23.6 in)

wall thickness of the basket 8mm load, bottom discharge 2-motion plow lid with hydraulic assist openings: 150mm filtrate, top cover: 250mm sightglass, 1-50mm feed, 1-25mm wash, bottom: 1-850mm with chute, 2 x powerpacks

Speed-RPM Maximum: 950. Load Weight: 450 kg (992.1 lb).

Type: Centrifuge-Basket

Subtype: Auto Discharge-Bottom

Manufacturer: Ellerwerk

Model: 736 UA

Condition: Used

Material: Stainless Steel Other

Basket Diameter: 1,250 mm (49.2 in)

Basket Depth: 600 mm (23.6 in)

basket wall thickness 12mm 316/Ti s/steel (1.4571) housing Gas tight at 0.2 bar pressure. hydraulic plow, powerpack

Filtration Area: 2.4 m² (25.3 ft²). Motor Power: 30 kW (40.2 HP). Speed-RPM Maximum: 950. Load Weight: 450 kg (992.1 lb). Gas Tight: Yes.
