Volume: 30m³ With stainless steel cover, mounted on cover is a 265mm inlet x 250mm outlet (1.4571) stainless steel rotary valve, manufactured by Waeschle, type ZGB.320.1.19.SS, serial number 58113.10, pressure rated 1,2bar @ 180 dgrees C, driven by a 1,5 KW electrical motor, manufactured by SEW, type R62D190L4, serial number 3001522303000197, 3~/50Hz/290-500V/maximum 1466rpm, CE confirm 1.4541 stainless steel tube and shell heater bank (calorifier), manufactured by Calorifer AG, serial number 5555 design pressure jacket 0,15 bar @ 250 degrees C design pressure tubeside 25 bar @ 250 degrees C, volume 260 liter, (910) 14,5mm diameter x 1972mm long 1.4541 stainless steel tubes, with welded on top and bottom cone section openings tubeside: (3) 25mm, (1) 15mm, openings jacket side (2) cone with 1200mm, mounted on (4) stainless steel lugs; (2) 17500 liter 316L (1.4541) stainless steel vertical cyclone separator, manufactured by TREMA GmbH, type GA 215 - OKRB-240, serial number 3234, internal pressure 0,1 bar @ 250 degrees C, bolted coned bottom section, weld slight coned top. 2142 mm diameter x 3760mm straight side x 1940mm cone section, total height 6800mm; (1) maximum 24,57 m³/sec 1.4541 stainless steel exhaust fan, manufactured by FIMA, type RMS1 U800 KGB GL360, serial number 72780/1, 331kW, rated 0.915 kg/m³ @ 133 degrees C, fan mounted on baseplate fan is clutch driven by a 550kW electrical motor, manufactured by Loher, type AMSA-450MB-02A, serial number 5125593, 3~/50Hz/500V/2990rpm 550 kW/500V/710 A/50 HZ/2990 rpm, EX proof, mounted on baseplate; Used as a pre-crystallizer for a Solid State Polymerization system.
