Plate and Frame Heat Exchanger 10 m² (107.6 ft²) Stainless Steel Austenitic For Sale - IPP# 222334

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: M30-FD

Condition: Unused

Material: Stainless Steel 316

Heat Transfer Surface Area: 938 m² (10,100 ft²)

Nozzle Schedule: - Inlets: (2) 12" - Outlets: (2) 12"

CRN: P-9782.27 channel plates 88.25 in. x 39 1/8in. x 0.6 mm thick Print weight 24,034 lbs

Hot-side Pressure: 20.7 bar (300 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Stainless Steel 316. Number of Plates: 588.

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: A10-BFD Type A

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 8.3 m² (89 ft²)

Length: 42 mm (1.65 in)

CS frame

Nozzle Schedule: - Nozzle size: 6" for process and service.. Cold-side Pressure: 150 bar (2,200 psi). Cold-side Temperature: 230 °C (446 °F). Hot-side Pressure: 150 bar (2,200 psi). Hot-side Temperature: 230 °C (446 °F). Housing Material: Carbon Steel. Number of Plates: 36.

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: A10-BFD

Condition: Used

Material: Stainless Steel 304

Heat Transfer Surface Area: 36.1 m² (389.1 ft²)

Hot-side Pressure: 11.4 bar (165 psi)

plate heat exchanger

Hot-side Temperature: 162.8 °C (325 °F). Number of Plates: 36.

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: 12" MA30-WFG

Condition: Used

Material: Hastelloy - B

Heat Transfer Surface Area: 179.8 m² (1,950 ft²)

Nozzle Schedule: Inlet/Outlet Size: 12"

Hastelloy B-2 plates 59 plates at 33.36 sq.ft. per plate. Rated for kbtu/hr=4079 Hot Side Flow Rate: 3750 gpm Cold Side Flow Rate: 800 gpm 12" inlets/outlets both sides. Shipping Weight: 14,000lbs.

Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 93.3 °C (200 °F). Housing Material: Carbon Steel. Number of Plates: 59.
