Hastelloy - C276 Pfaudler Tray Column - IPP# 225352

Type: Column

Subtype: Tray

Manufacturer: Pfaudler

Condition: Used

Material: Hastelloy - C276

Diameter (1): 101.6 mm (4 in)

Length (overall): 1,219 mm (48 in)

Distillation column with reflux splitter (10) Glitsch cartridge type perforated trays with 6" spacing. 228 empty weight. With reflux splitter.

Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F).

Type: Column

Subtype: Tray

Manufacturer: Pfaudler

Condition: Used

Material: Hastelloy - C276

Diameter (1): 76.2 mm (3 in)

Length (overall): 914.4 mm (36 in)

3" diameter x 36" straight side, With (10) Glitsch cartridge type perforated sieve trays.

Top head is a 3" to 1.5" concentric reducer. With reflux splitter and decanter tank.

Pressure: 20.7 bar (300 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Number Of Trays: 10. Tray Type: Sieve Tray.

Type: Column

Subtype: Tray

Manufacturer: Pfaudler

Condition: Used

Material: Hastelloy - C276

Diameter (1): 101.6 mm (4 in)

Length (overall): 1,219 mm (48 in)

Distillation column with reflux splitter (10) Glitch cartridge type perforated trays Empty weight 228 lbs. With reflux splitter

Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Number Of Trays: 10.

Type: Column

Subtype: Tray

Manufacturer: Pfaudler

Condition: Used

Material: Stainless Steel 316

Diameter (1): 203.2 mm (8 in)

Length (overall): 3,048 mm (120 in)

distillation column reflux splitter and decanter tank National board stamped Rated 150/FV @ -20 to 450 degrees F internal. 8-1/8" ID x 117-3/8" length, bolted top and bottom] Schedule 20 straight side, bottom head is 0.250" thickness Top head is 8" x 3" concentric reducer with 3" 150 lb flanged end, bottom head is dished.
Column has (11) Glitch cartridge type perforated trays, 0.074 thick 316SS.
485 lbs empty weight.

Pressure: 10.3 bar (150 psi). Temperature: 232.2 °C (450 °F).
