Stainless Steel 316 Alfa Laval M15-BFM8 Plate and Frame Heat Exchanger - IPP# 229489

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: M30-FD

Condition: Unused

Material: Stainless Steel 316

Heat Transfer Surface Area: 938 m² (10,100 ft²)

Nozzle Schedule: - Inlets: (2) 12" - Outlets: (2) 12"

CRN: P-9782.27 channel plates 88.25 in. x 39 1/8in. x 0.6 mm thick Print weight 24,034 lbs

Hot-side Pressure: 20.7 bar (300 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Stainless Steel 316. Number of Plates: 588.

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: A10-BFD Type A

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 8.3 m² (89 ft²)

Length: 42 mm (1.65 in)

CS frame

Nozzle Schedule: - Nozzle size: 6" for process and service.. Cold-side Pressure: 150 bar (2,200 psi). Cold-side Temperature: 230 °C (446 °F). Hot-side Pressure: 150 bar (2,200 psi). Hot-side Temperature: 230 °C (446 °F). Housing Material: Carbon Steel. Number of Plates: 36.

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: P-22 S

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 14.4 m² (154.7 ft²)

Nozzle Schedule: - Inlets and Outlets: 3" (with a separate 2" inlet and outlet)

Inlets and outlets are 3", with a separate 2" inlet and outlet

Cold-side Pressure: 6.9 bar (100 psi). Cold-side Temperature: 121.1 °C (250 °F). Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 121.1 °C (250 °F). Housing Material: Carbon Steel. Number of Plates: 22.

Type: Heat Exchanger

Subtype: Plate and Frame

Manufacturer: Alfa Laval

Model: 16-FG

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 3.2 m² (34 ft²)

Cold-side Pressure: 10.3 bar (150 psi)

plate and frame heat exchanger

Cold-side Temperature: 121.1 °C (250 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 121.1 °C (250 °F).
