plate heat exchanger, Certification: CE0090, pressure both side 10 bar @ 120 degrees C (31.9 & 31.9 liter) 1492kw, 316 stainless steel (1.4404) plates, carbon steel pressure plate and frame. Heat Transfer Surface Area: 20.2 m² (217.4 ft²). Nozzle Schedule: openings : 4-100mm 316Ti stainless steel (1.4571). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 120 °C (248 °F). Housing Material: Carbon Steel. Number of Plates: 77.

plate heat exchanger, (wash column heater), pressure both sides -1/6 bar @ -20/100 degrees C (37.8 & 37.8 liter) 68.470kw, carbon steel pressure plates and frame. Heat Transfer Surface Area: 20.6 m² (221.7 ft²). Nozzle Schedule: openings 2-200mm 316Ti stainless steel (1.4571), 2-50mm 316Ti stainless steel (1.4571). Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 100 °C (212 °F). Housing Material: Carbon Steel. Number of Plates: 45.

plate heat exchanger (side discharge cooler), pressure on both sides -1/6 bar @ -10/100 degrees C (2.1 & 2.1 liter) 11.8kw, 316Ti stainless steel (1.4571) plates, carbon steel pressure plates and frame. Heat Transfer Surface Area: 1.4 m² (15.1 ft²). Nozzle Schedule: openings 4-25mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 100 °C (212 °F). Housing Material: Carbon Steel. Number of Plates: 11.

plate heat exchanger (bottoms cooler) pressure both sides -1/6 bar @ -10/120 degrees C (25.2 liter) 768kw openings 4-80mm 316Ti stainless steel (1.4571), carbon steel pressure plates and frame Heat Transfer Surface Area: 15.9 m² (171 ft²). Nozzle Schedule: openings 4-80mm 316Ti stainless steel (1.4571). Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 120 °C (248 °F). Housing Material: Carbon Steel. Number of Plates: 61.

Type: Plate heat exchanger (pre-heater) Plate material: 316L stainless steel (1.4404) pressure on both sides -5/6 bar @ 120 degrees C (91 & 89 liter) carbon steel pressure plates and frame, 316L stainless steel (1.4571) Heat Transfer Surface Area: 50.8 m² (546.8 ft²). Nozzle Schedule: openings 4-100mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 120 °C (248 °F). Housing Material: Carbon Steel. Number of Plates: 78.

plate heat exchanger (pre-heater) pressure both sides 8 bar @ 130 degrees C (6.8 liter) carbon steel pressure plates and frame, Heat Transfer Surface Area: 10 m² (107.6 ft²). Nozzle Schedule: openings side A: 2-50mm, side B: 2-50mm. Cold-side Pressure: 8 bar (116 psi). Cold-side Temperature: 130 °C (266 °F). Hot-side Pressure: 8 bar (116 psi). Hot-side Temperature: 130 °C (266 °F). Housing Material: Carbon Steel. Number of Plates: 71.

plate heat exchanger (product cooler), pressure both sides -1/10 bar @ 140 degrees C (3.2 & 3.2 liter) 164kw, 316Ti stainless steel (1.4571), carbon steel pressure plates and frame. Heat Transfer Surface Area: 2.3 m² (24.8 ft²). Nozzle Schedule: openings 4-50mm 316Ti stainless steel (1.4571). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 140 °C (284 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 140 °C (284 °F). Housing Material: Carbon Steel. Number of Plates: 17.

carbon steel pressure plates and frame, Heat Transfer Surface Area: 213.6 m² (2,299 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 95 °C (203 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 95 °C (203 °F). Number of Plates: 356.

carbon steel pressure plates and frame, Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 65 °C (149 °F). Number of Plates: 34.

Plate Pack7.52"--7.91" Certified by Plate Concepts Inc. Heat Transfer Surface Area: 33.4 m² (359.7 ft²). Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 93.3 °C (200 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 93.3 °C (200 °F). Housing Material: Carbon Steel.

• Sections: 4 (1-17 plates, 1-20 plates, 1-7 plates, 1-10 plates) Heat Transfer Surface Area: 30 m² (322.9 ft²). Nozzle Schedule: Openings: 10-1 1/2" (37mm), 2-1" (25mm). Housing Material: Stainless Steel Other. Number of Plates: 54.

plate heat exchanger 8" connections. Heat Transfer Surface Area: 93 m² (1,001 ft²). Cold-side Pressure: 4 bar (58 psi). Hot-side Pressure: 4 bar (58 psi). Number of Plates: 114.

• Capacity: 500 gallon/hour (2270 liter/hour)
• Plate sections: A-(15); B-(43); C-(15) Heat Transfer Surface Area: 14.8 m² (159.3 ft²). Length: 1,067 mm (42 in). Nozzle Schedule: Openings: 3-50mm inlets, 2-38mm outlets . Housing Material: Carbon Steel. Number of Plates: 73.

• Capacity: 500 gallon/hour (2270 liter/hour)
• Plate sections: A-(15); B-(43); C-(15) Heat Transfer Surface Area: 14.8 m² (159.3 ft²). Length: 1,067 mm (42 in). Nozzle Schedule: Openings: 3-50mm inlets, 2-38mm outlets . Housing Material: Carbon Steel. Number of Plates: 73.

• 1,000 gallon/hour (4540 liter/hour) capacity
• Plate sections: A-(15); B-(43); C-(15) Heat Transfer Surface Area: 30.7 m² (330.5 ft²). Length: 1,626 mm (64 in). Nozzle Schedule: Openings: 7-75 inlets/outlets. Housing Material: Carbon Steel. Number of Plates: 73.

Manual plate closure Plates are divided into (2) sections: A-(18); B-(49). Heat Transfer Surface Area: 10.8 m² (116.3 ft²). Length: 1,676 mm (66 in). Nozzle Schedule: Openings: 9-50mm inlets/outlets. . Number of Plates: 67.

Max working pressure (Side A) 6 bar @ 50 degrees C; (Side B) 6 bar @ 50 degrees C Capacity (Side A) 49.8 liter; (Side B) 46.0 liter). (2) carbon steel pressure plates. Heat Transfer Surface Area: 6 m² (64.6 ft²). Length: 609.6 mm (24 in). Nozzle Schedule: Openings: inlets: 1-1 1/2", 1-3"; outlets 1-1 1/2", 1-3" . Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 50 °C (122 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 50 °C (122 °F). Number of Plates: 13.

Volume: 13 liters on both sides carbon steel pressure plates. Heat Transfer Surface Area: 15 m² (161.5 ft²). Cold-side Pressure: 1 bar (14.5 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 1 bar (14.5 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 40.

Heat Transfer Surface Area: 10.7 m² (115.6 ft²). Nozzle Schedule: Openings: 4-50mm.. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 100 °C (212 °F). Number of Plates: 31.

Heat exchanged: 220 kw single pass both sides

• Flow rate process side: 240 m3/hr
• Flow rate service side: 63.31 m3/hr
• Inlet temperature process side: 28 deg C
• Inlet temperature service side: 24 deg C
• Outlet temperature process side: 27.3 deg C
• Outlet temperature service side: 27 deg C Heat Transfer Surface Area: 37.2 m² (400.4 ft²). Nozzle Schedule: Openings process side: 2-125mm - Openings service side: 2-125mm. Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 60 °C (140 °F). Housing Material: Carbon Steel. Number of Plates: 62.

• Flow configuration: Single pass both sides
• Flow rate: 39,500 kg/hr c/steel frame Heat Transfer Surface Area: 19.6 m² (211 ft²). Nozzle Schedule: openings process side: 2- 80mm, process side 2- 80mm,. Hot-side Pressure: 6 bar (87 psi). Housing Material: Carbon Steel. Number of Plates: 56.

Heat exchanged: 220 kw single pass both sides Flow rate (process side): 240 m3/hr Flow rate (service side): 63.31 m3/hr Inlet temperature (process side): 28 deg C Inlet temperature (service side): 24 deg C Outlet temperature (process side): 27.3 deg C Outlet temperature (service side): 27 deg C Heat Transfer Surface Area: 37.2 m² (400.4 ft²). Nozzle Schedule: Openings (process side): 2- 125mm - Openings (service side): 2-125mm. Cold-side Temperature: -17.8 °C (0 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 60 °C (140 °F). Housing Material: Carbon Steel. Number of Plates: 62.

Divider plate: 1 x divider plate Heat Transfer Surface Area: 39.9 m² (429.5 ft²). Hot-side Pressure: 10 bar (145 psi). Housing Material: Stainless Steel Other. Number of Plates: 105.

plate heat exchanger Flow rate: 50 m3/hr Heat Transfer Surface Area: 7 m² (75.3 ft²). Nozzle Schedule: Number of openings: 8 (4-75mm and 4-50mm). Hot-side Pressure: 6 bar (87 psi). Housing Material: Stainless Steel Other. Number of Plates: 19.

Flow rate: 50 m3/hr Heat Transfer Surface Area: 11.1 m² (119.5 ft²). Nozzle Schedule: Number of openings: 4-75mm and 4-50mm. Hot-side Pressure: 6 bar (87 psi). Housing Material: Stainless Steel Other. Number of Plates: 30.

304 s/steel divider plate Heat Transfer Surface Area: 9 m² (96.4 ft²). Nozzle Schedule: 4-50mm openings, divider plate with 2-50mm. Hot-side Pressure: 4 bar (58 psi). Housing Material: Stainless Steel Other. Number of Plates: 56.

Heat Transfer Surface Area: 53.1 m² (571.4 ft²). Nozzle Schedule: 4-150mm openings. Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 65.6 °C (150 °F).

plate heat exchanger, manufacturers #30102-23402, stainless steel plates. Heat Transfer Surface Area: 4.6 m² (49.5 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F). Number of Plates: 21.

Tested to 150 psi Inlets and outlets are 2.5" flanged. Heat Transfer Surface Area: 12.4 m² (134 ft²). Nozzle Schedule: - Inlet/outlet size: 2.5" flanged. Cold-side Pressure: 6.9 bar (100 psi). Cold-side Temperature: 160 °C (320 °F). Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 160 °C (320 °F).

plate and shell horizontal cylindrical heat exchanger CE0409 design pressure plate side -1/25 barg @ 150 degrees C (52 liter) shell side -1/25 barg @ 150 degrees C (51 liter) stainless steel cylindrical plate, stainless steel cylindrical shell with weld flat ends Cold-side Pressure: 25 bar (362.6 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 25 bar (362.6 psi). Hot-side Temperature: 150 °C (302 °F). Housing Material: Stainless Steel Other.

design BC-12 0.45 squaremeter heat exchange surface per plate, (plate package min 851mm, max 870mm), plate package is 868mm 321 (1.4541) stainless steel frame Heat Transfer Surface Area: 47.5 m² (511.5 ft²). Cold-side Pressure: 12 bar (174 psi). Cold-side Temperature: 115 °C (239 °F). Hot-side Pressure: 12 bar (174 psi). Hot-side Temperature: 115 °C (239 °F). Housing Material: Stainless Steel 321. Number of Plates: 105.

316 SS plates with CS frame, rated for 199585 lbs./hr. water and 210539 lbs./hr. glycol. Heat Transfer Surface Area: 71 m² (764 ft²). Length: 1,397 mm (55 in). Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 115 °C (239 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 115 °C (239 °F). Housing Material: Carbon Steel. Number of Plates: 73.

Plate pack min=1.18, max=1.27. 16.1 sq.ft is 6 plates. Heat Transfer Surface Area: 1.5 m² (16.1 ft²). Cold-side Pressure: 5.2 bar (75 psi). Cold-side Temperature: 148.9 °C (300 °F). Hot-side Pressure: 5.2 bar (75 psi). Hot-side Temperature: 148.9 °C (300 °F). Number of Plates: 6.

plate pack min=1.18, max=1.27. 16.1 sq.ft is 6 plates. Heat Transfer Surface Area: 1.5 m² (16.1 ft²). Cold-side Pressure: 5.2 bar (75 psi). Cold-side Temperature: 148.9 °C (300 °F). Hot-side Pressure: 5.2 bar (75 psi). Hot-side Temperature: 148.9 °C (300 °F). Number of Plates: 6.

Process sidde rated 45 PSI @ -30/+122 degrees F. Service side rated 30 PSI @ -30/+122 degrees F. Heat Transfer Surface Area: 10.8 m² (116.3 ft²). Nozzle Schedule: - Openings: 2-3" process side, 2-2" service side. Cold-side Pressure: 2.1 bar (30 psi). Cold-side Temperature: 50 °C (122 °F). Hot-side Pressure: 3.1 bar (45 psi). Hot-side Temperature: 50 °C (122 °F).

plate heat exchanger Plate rack 47.40" minimum 49.77" maximum. Heat Transfer Surface Area: 169.5 m² (1,825 ft²). Nozzle Schedule: Openings: process side 2-8' service side 2-8".. Cold-side Pressure: 5.2 bar (75 psi). Cold-side Temperature: 65.6 °C (150 °F). Hot-side Pressure: 5.2 bar (75 psi). Hot-side Temperature: 65.6 °C (150 °F).

maximum temperature is 410 degrees F Heat Transfer Surface Area: 185.8 m² (2,000 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 135 °C (275 °F). Number of Plates: 360.

Maximum temperature 410 degrees F gasketed plates. Heat Transfer Surface Area: 139.4 m² (1,500 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 135 °C (275 °F). Number of Plates: 189.

Media on hot and cold side: Water Gasket material: Nitrile Capacity vs. gallons 93.6 USG Heat Transfer Surface Area: 146.1 m² (1,573 ft²). Length: 2,134 mm (84 in). Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 110 °C (230 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 110 °C (230 °F). Number of Plates: 195.

CRN L-4646.57 Print weight is 6247 lbs The frame plates are SA-516-70 CS With (418) channel plates Heat Transfer Surface Area: 259.2 m² (2,790 ft²). Nozzle Schedule: Openings - (2) 6" inlets (2) 6" outlets. Hot-side Pressure: 20.7 bar (300 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Carbon Steel. Number of Plates: 453.

CRN L-4646.57 Frame plates are SA-516-70 CS Print weight is 6247 lbs With (418) channel plates Heat Transfer Surface Area: 259.2 m² (2,790 ft²). Nozzle Schedule: Openings - (2) 6" inlets (2) 6" outlets. Hot-side Pressure: 20.7 bar (300 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Stainless Steel 316. Number of Plates: 453.

CRN L-4646.57 frame plates are SA-516-70 CS With (418) channel plates print weight is 6247 lbs Heat Transfer Surface Area: 259.2 m² (2,790 ft²). Nozzle Schedule: 6" inlets, (2) 6" outlets,. Hot-side Pressure: 20.7 bar (300 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Carbon Steel. Number of Plates: 453.

vertical plate and frame, 55- 316 stainless steel plates, Fluid group # 1 inlet S-1 & outlet S-2, fluid group # 2 Inlet S3 and outlet S4 Weight with load 1238 KG, weight without load 1103 KG. EPDM clip on gaskets. Heat Transfer Surface Area: 11.7 m² (126 ft²). Length: 1,155 mm (45.5 in). Nozzle Schedule: Nozzles are 6". Cold-side Pressure: 5.9 bar (85.3 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 5.9 bar (85.3 psi). Hot-side Temperature: 100 °C (212 °F). Housing Material: Carbon Steel.

Flow direction is counter current, inlets and outlets are 6" flanges. Estimated weight, 4,273 lbs. Heat Transfer Surface Area: 128.1 m² (1,379 ft²). Number of Plates: 235.

CRN: P-9782.27 channel plates 88.25 in. x 39 1/8in. x 0.6 mm thick Print weight 24,034 lbs Heat Transfer Surface Area: 938.4 m² (10,101 ft²). Nozzle Schedule: - Inlets: (2) 12" - Outlets: (2) 12". Hot-side Pressure: 20.7 bar (300 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Stainless Steel 316. Number of Plates: 588.

welded plate heat exchanger with 316TiSS wetted parts horizontal design 0.7 bar working pressure 90 dm3 capacity 125 dm3 capacity All wetted parts are material Z2CND 17-12 France standard, (3156TiSS) The rectangular housing is 260 mm wide, 3200 mm long Empty weight 1200 Kg Heat Transfer Surface Area: 18 m² (194 ft²). Nozzle Schedule: Openings: Service side (2) 150mm, process side (2) 50mm, (1) 200mm . Cold-side Pressure: 5 bar (72.5 psi). Cold-side Temperature: 50 °C (122 °F). Hot-side Pressure: 3 bar (43.5 psi). Hot-side Temperature: 150 °C (302 °F). Housing Material: Carbon Steel.

plate heat exchanger Heat Transfer Surface Area: 9.9 m² (107 ft²). Nozzle Schedule: - Openings: 4-3". Cold-side Pressure: 10 bar (145 psi). Hot-side Pressure: 10 bar (145 psi). Number of Plates: 27.

pressure on both sides -1/10 bar @ -10/200 degrees C (2.9/3.2 liter) 150kw fully insulated, Heat Transfer Surface Area: 3.1 m² (33.4 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 200 °C (392 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 200 °C (392 °F). Number of Plates: 24.

pressure side A -1 /10 bar @ -10/200 degrees C (2.06 liter) side B -1/10 bar @ -10/200 degrees C (2.33 liter), fully insulated Heat Transfer Surface Area: 1.9 m² (20.5 ft²). Number of Plates: 16.

150kw pressure on both sides -1 /10 bar @ -15/160 degrees C (6/6.3 liter), CE0035 certified Heat Transfer Surface Area: 6.1 m² (65.7 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 160 °C (320 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 160 °C (320 °F). Number of Plates: 34.

pressure both sides -1/6 bar @ -10/200/150 degrees C (16/16 liter) Heat Transfer Surface Area: 12.8 m² (137.8 ft²).

Sigma 27 NCL plate heat exchanger Heat Transfer Surface Area: 2.5 m² (26.5 ft²). Cold-side Pressure: 7 bar (101.5 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 7 bar (101.5 psi). Hot-side Temperature: 150 °C (302 °F). Housing Material: Hastelloy - C276. Number of Plates: 12.

Heat Transfer Surface Area: 4.5 m² (48.4 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F).

Heat Transfer Surface Area: 4.5 m² (48.4 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F).

Heat Transfer Surface Area: 4.5 m² (48.4 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F).

Heat Transfer Surface Area: 4.5 m² (48.4 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F).

Heat Transfer Surface Area: 4.5 m² (48.4 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F).

Heat Transfer Surface Area: 4.5 m² (48.4 ft²). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F).

(total volume 64,8 liter each side) each plate 0,65m² Heat Transfer Surface Area: 54 m² (580.7 ft²). Nozzle Schedule: Openings on product side: 2 DN100. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 140 °C (284 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 140 °C (284 °F). Housing Material: Carbon Steel. Number of Plates: 83.

rated 6 bar @ 30 degrees C, 3.5 liters with 40 mm inlets and outlets Heat Transfer Surface Area: 1.6 m² (17.2 ft²). Nozzle Schedule: - Inlet/outlet size: 40 mm. Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 30 °C (86 °F). Number of Plates: 14.

Part number: 981398 MDMT is 32 degrees F @100 psi Heat Transfer Surface Area: 1.39 m² (15 ft²). Nozzle Schedule: - Hot lines in and out: 2" NPT - Cold lines in and out: 2" NPT. Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 100 °C (212 °F).

Part number: 981398 MDMT is 32 degrees F @100 psi. Heat Transfer Surface Area: 1.39 m² (15 ft²). Nozzle Schedule: - Hot lines in and out: 2" NPT - Cold lines in and out: 2" NPT. Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 100 °C (212 °F).

Part number: 981398 MDMT is 32 degrees F @100 psi. Heat Transfer Surface Area: 1.39 m² (15 ft²). Nozzle Schedule: - Hot lines in and out: 2" NPT - Cold lines in and out: 2" NPT. Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 100 °C (212 °F).

pressure side 1= -1/6 bar @ 170 deg C (2.9ltr) side 2= -1/6 bar @ 170 deg C (3.1ltr) test pressure both sides 10 bar c/steel frame Heat Transfer Surface Area: 2.2 m² (23.8 ft²). Nozzle Schedule: - Openings: 4-50mm. Housing Material: Carbon Steel. Number of Plates: 28.

pressure side 1= -1/6 bar @ 170 deg C (2.9ltr) side 2= -1/6 bar @ 170 deg C (3.1ltr) test pressure both sides 10 bar c/steel frame Heat Transfer Surface Area: 2.2 m² (23.8 ft²). Nozzle Schedule: - Openings: 4-50mm. Housing Material: Carbon Steel. Number of Plates: 28.

pressure side 1= -1/6 bar @ 170 deg C (1.8ltr) side 2= -1/6 bar @ 170 deg C (2ltr) test pressure both sides 10 bar c/steel frame Heat Transfer Surface Area: 1.36 m² (14.6 ft²). Nozzle Schedule: - Openings: 4-50mm. Housing Material: Carbon Steel. Number of Plates: 18.

pressure side 1= 6 bar @ 170 deg C (1.3ltr) side 2= 6 bar @ 170 deg C (1.5ltr) test pressure both sides 10 bar c/steel frame Heat Transfer Surface Area: 1.02 m² (11 ft²). Nozzle Schedule: Openings: 4-50mm. Housing Material: Carbon Steel. Number of Plates: 14.

Heat Transfer Surface Area: 16.3 m² (175.9 ft²). Nozzle Schedule: with (2) 4" openings cold side; (2) 4" opening hot side. Hot-side Pressure: 8.6 bar (125 psi). Hot-side Temperature: 121.1 °C (250 °F).

pressure side A: 8 bar @ -10/+100 deg C (12.5 liter), side B: 8 bar @ -10/+100 deg C (13 liter) Heat Transfer Surface Area: 11.8 m² (127 ft²). Nozzle Schedule: - Plate openings: 4-50mm. Housing Material: Stainless Steel 316. Number of Plates: 61.

pressure side A: 8 bar @ -10/+100 deg C (12.5 liter), side B: 8 bar @ -10/+100 deg C (13 liter) Heat Transfer Surface Area: 11.8 m² (127 ft²). Nozzle Schedule: - Plate openings: 4-50mm. Housing Material: Stainless Steel 316. Number of Plates: 58.

• End plate material: Carbon steel
• End plate features: Threaded rods Heat Transfer Surface Area: 51 m² (549 ft²). Nozzle Schedule: - Plate openings: 2-100mm, 2-80mm. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F). Housing Material: Carbon Steel. Number of Plates: 80.

End plate features: Threaded rods Heat Transfer Surface Area: 53 m² (570.5 ft²). Nozzle Schedule: - Plate openings: 2-100mm, 2-80mm. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F). Housing Material: Carbon Steel. Number of Plates: 82.

• End plates features: Threaded rods Heat Transfer Surface Area: 51 m² (549 ft²). Nozzle Schedule: - Plate openings: 2-100mm, 2-80mm. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 100 °C (212 °F). Housing Material: Carbon Steel. Number of Plates: 80.

Heat Transfer Surface Area: 112 m² (1,206 ft²). Nozzle Schedule: - Openings: - Inlet: 2-100mm - Outlet: 2-100mm. Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 110 °C (230 °F).

CS frame Heat Transfer Surface Area: 8.3 m² (89 ft²). Nozzle Schedule: - Nozzle size: 6" for process and service.. Housing Material: Carbon Steel. Number of Plates: 36.

plate heat exchanger Heat Transfer Surface Area: 8.3 m² (89.1 ft²). Hot-side Pressure: 11.4 bar (165 psi). Hot-side Temperature: 162.8 °C (325 °F). Number of Plates: 36.

Hastelloy B-2 plates 59 plates at 33.36 sq.ft. per plate. Rated for kbtu/hr=4079 Hot Side Flow Rate: 3750 gpm Cold Side Flow Rate: 800 gpm 12" inlets/outlets both sides. Shipping Weight: 14,000lbs. Heat Transfer Surface Area: 179.8 m² (1,935 ft²). Nozzle Schedule: Inlet/Outlet Size: 12". Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 93.3 °C (200 °F). Housing Material: Carbon Steel. Number of Plates: 59.

• Hot Side Rating: 150 PSIG at 230 degrees F, MDMT is +32 degrees F at 150 psi
• Cold Side Rating: 150 PSIG at 230 degrees F, MDMT is +32 degrees F at 150 psi
• Part #: S-612-31-073-001
• Heat Exchange Capacity: 12,713 MM Btu/hr
• Connection Sizes: 6"
• Surface per Plate: 8.07 Heat Transfer Surface Area: 53.2 m² (573 ft²). Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 110 °C (230 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 110 °C (230 °F).

316 SS plate, CS frame, Plate and Frame Heat Exchanger for APV Crepaco Minimum -20 degrees F @ 225 PSI 150 psi flange set. Heat Transfer Surface Area: 20.9 m² (225 ft²). Nozzle Schedule: Hot and cold side inlets and outlets, 4" . Hot-side Pressure: 15.5 bar (225 psi). Hot-side Temperature: 93.3 °C (200 °F). Housing Material: Carbon Steel. Number of Plates: 166.

• Com number: EP6811-02
• Number of openings: 4
• C276 plates Heat Transfer Surface Area: 7.6 m² (81.8 ft²). Nozzle Schedule: 4-100mm openings. Number of Plates: 29.

Chilled water service Size unknown, insulated Heat Transfer Surface Area: 9.3 m² (100 ft²).

• Certification: Certified by WFT GmbH MDMT 319 degrees F at 450 psi
• Volume: 89.70/90.3
• WD (Water Distribution): 10-300 Heat Transfer Surface Area: 9.3 m² (100 ft²). Nozzle Schedule: - Nozzles: Four 4"-150 lb. flange, with 2 turned to 90 degrees. Hot-side Pressure: 31 bar (450 psi). Hot-side Temperature: 195 °C (383 °F). Housing Material: Carbon Steel. Number of Plates: 150.

• Primary side volume: 6.5 liters
• Secondary side volume: 6.5 liters Heat Transfer Surface Area: 2.5 m² (26.6 ft²). Nozzle Schedule: openings (4) DN50. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 19.

• Inlet and outlet (cold side): Two, 3" flanges
• Inlet and outlet (hot side): Two, # " flanges (size not specified) Heat Transfer Surface Area: 19.2 m² (207 ft²). Nozzle Schedule: - Inlet and outlet (cold side): Two, 3" flanges - Inlet and outlet (hot side): Two, # " flanges (size not specified). Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 93.3 °C (200 °F).

plate heat exchanger CS head plates, (2) 4" inlets and (2) 4" outlets. Heat Transfer Surface Area: 13.9 m² (150 ft²). Nozzle Schedule: - Inlets: (2) 4" - Outlets: (2) 4". Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 148.9 °C (300 °F). Housing Material: Carbon Steel.

plate heat exchanger CS head plates, (2) 4" inlets and (2) 4" outlets. Heat Transfer Surface Area: 13.9 m² (150 ft²). Nozzle Schedule: - Inlets: (2) 4" - Outlets: (2) 4". Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 148.9 °C (300 °F). Housing Material: Carbon Steel.

Titanium plate heat exchanger CS end plates. (2) 2.5" inlets; (2) 2.5" outlets Temperature in 95F hot side 194F cold side , temperature out 131F hot side 156F cold side . Heat Transfer Surface Area: 4.6 m² (50 ft²). Nozzle Schedule: - Inlets: (2) 2.5" - Outlets: (2) 2.5". Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 135 °C (275 °F). Housing Material: Carbon Steel.

Type: Plate heat exchanger (cold trap) pressure both sides -1/6 bar @ 60/200 degrees C, Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 200 °C (392 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 200 °C (392 °F).

heat exchanger (bottoms cooler) CE pressure -1/10 bar @ 60 degrees C (26/25 liter) 316L stainless steel (1.4404) plates, carbon steel skeleton frame Heat Transfer Surface Area: 13.1 m² (141 ft²). Nozzle Schedule: openings: 4-100mm. Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 60 °C (140 °F). Housing Material: Carbon Steel. Number of Plates: 34.

Minimal design metal temp.=-20 degrees F at 200 psi. Heat Transfer Surface Area: 84.7 m² (912 ft²). Length: 3,962 mm (156 in). Cold-side Pressure: 13.8 bar (200 psi). Cold-side Temperature: 162.8 °C (325 °F). Hot-side Pressure: 13.8 bar (200 psi). Hot-side Temperature: 162.8 °C (325 °F).

Minimal design metal temp.=-20 degrees F at 200 psi. Heat Transfer Surface Area: 84.7 m² (912 ft²). Length: 3,048 mm (120 in). Cold-side Pressure: 13.8 bar (200 psi). Cold-side Temperature: 162.8 °C (325 °F). Hot-side Pressure: 13.8 bar (200 psi). Hot-side Temperature: 162.8 °C (325 °F).

each plate 1.40 Sq.ft Gasket material EDPM. Carbon steel frame. plate pack 3 & 3/8", min. plate pack 3 & 1/4". Four 2" sanitary clamp connections Heat Transfer Surface Area: 2.7 m² (29.4 ft²). Nozzle Schedule: . Hot-side Pressure: 150 bar (2,176 psi). Hot-side Temperature: 300 °C (572 °F). Housing Material: Carbon Steel. Number of Plates: 21.

ITT Part number EX5400800009800 Plate pack range from 3.7" to 3.8". Heat Transfer Surface Area: 1.86 m² (20 ft²). Nozzle Schedule: Openings: (4) 2".. Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 7.

ITT Part number EX5400800009800 Plate pack range from 3.7" to 3.8". Heat Transfer Surface Area: 1.86 m² (20 ft²). Nozzle Schedule: Openings: (4) 2". . Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 7.

Inlets and outlets are 3", with a separate 2" inlet and outlet Heat Transfer Surface Area: 14.4 m² (154.7 ft²). Nozzle Schedule: - Inlets and Outlets: 3" (with a separate 2" inlet and outlet). Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 121.1 °C (250 °F).

4" inlets and outlets. Heat Transfer Surface Area: 9.3 m² (100 ft²). Length: 1,219 mm (48 in). Nozzle Schedule: - Inlets and Outlets: 4" .

pressure both sides -1/10 bar @ -50/150 degrees C (18 liter/17 liter) fully insulated, CE-0036, Heat Transfer Surface Area: 8.1 m² (87.2 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 34.

pressure both sides -1/10 bar @ -30/150 degrees C (3 liter/4 liter) CE0409, fully insulated, Heat Transfer Surface Area: 2.3 m² (24.6 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 32.

Titanium/321 (1.4401) stainless steel plate heat exchanger, pressure side 1 -1/6 bar @ -20/150 degrees C (32 liter), side 2 -1/6 bar @ -20/150 degrees C (33 liter), plate material side 1 321 (1.4401) stainless steel, side 2 Titanium, Heat Transfer Surface Area: 12 m² (129.2 ft²). Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 150 °C (302 °F).

160 kw Heat Transfer Surface Area: 20 m² (215.3 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 120 °C (248 °F). Number of Plates: 75.

Heat Transfer Surface Area: 2.3 m² (24.2 ft²). Nozzle Schedule: 4-4" openings. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 140 °C (284 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 140 °C (284 °F). Number of Plates: 11.

carbon steel frame Heat Transfer Surface Area: 1.3 m² (14 ft²). Nozzle Schedule: 4-1"Openings,. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 140 °C (284 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 140 °C (284 °F). Housing Material: Carbon Steel. Number of Plates: 28.

c/steel frame Heat Transfer Surface Area: 0.2 m² (2.2 ft²). Nozzle Schedule: 4-1" openings,. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 140 °C (284 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 140 °C (284 °F). Housing Material: Carbon Steel.

Vertical thermo panel bank condenser / heat exchanger (plate pack in a cylindrical shell) Pressure plate side: 10 bar @ 110 degrees C (190 liter) Shell side: 10 bar @ 250 degrees C (2700 liter) (38) 316L (1.4404) stainless steel Thermo plates, Free space: 10mm Spot pattern: 47 x 31.25mm 316L (1.4404) stainless steel shell, weld dished heads Heat Transfer Surface Area: 96 m² (1,033 ft²). Length: 2,289 mm (90.1 in). Nozzle Schedule: Openings: Plate side - 2-150mm, shell side - 1-700mm (top head), 1-200mm, 1-150mm (bottom head). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 250 °C (482 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 110 °C (230 °F). Number of Plates: 38.

Vertical thermo panel bank condenser / heat exchanger (plate pack in a cylindrical shell) Pressure plate side: 10 bar @ 110 degrees C (12 liter) Shell side: 10 bar @ 250 degrees C (85 liter) (12) 316L (1.4404) stainless steel Thermo plates, 316L (1.4404) stainless steel shell, weld dished heads, Heat Transfer Surface Area: 6.5 m² (70 ft²). Nozzle Schedule: Openings: Plate side - 2-200mm, shell side - 1-50mm (top head), 1-50mm (bottom head), 1-40mm (bottom head). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 250 °C (482 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 110 °C (230 °F). Housing Material: Stainless Steel 316. Number of Plates: 12.

CS heads Titanium plates NBRP Glued Gaskets. Dry weight 13,020 lbs. Flooded weight 18647 lbs. 4 connections/openings, 14” diameter each. Previous use 10% Ammonium Molybdate Solution /Water. Heat Transfer Surface Area: 748.8 m² (8,060 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 65.6 °C (150 °F). Housing Material: Carbon Steel. Number of Plates: 407.

CS heads NB stamped Titanium plates NBRP Glued Gaskets. Dry weight 13,020 lbs. Flooded weight 18647 lbs. 4 connections/openings, 14” diameter each. Previous use 10% Ammonium Molybdate Solution /Water. Heat Transfer Surface Area: 748.8 m² (8,060 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 65.6 °C (150 °F). Housing Material: Carbon Steel. Number of Plates: 407.

CS heads NB stamped Titanium plates NBRP Glued Gaskets. Dry weight 13,020 lbs. Flooded weight 18647 lbs. 4 connections/openings, 14” diameter each. Previous use 10% Ammonium Molybdate Solution /Water. Heat Transfer Surface Area: 748.8 m² (8,060 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 65.6 °C (150 °F). Housing Material: Carbon Steel. Number of Plates: 407.

CS heads Titanium plates, NBRP Glued Gaskets. Dry weight 13,020 lbs. Flooded weight 18647 lbs. 4 connections/openings, 14” diameter each. Previous use 10% Ammonium Molybdate Solution /Water. Heat Transfer Surface Area: 748.8 m² (8,060 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 65.6 °C (150 °F). Housing Material: Carbon Steel. Number of Plates: 407.

CS heads NB stamped Titanium plates, NBRP Glued Gaskets. Dry weight 13,020 lbs. Flooded weight 18647 lbs. 4 connections/openings, 14” diameter each. Previous use 10% Ammonium Molybdate Solution /Water. Heat Transfer Surface Area: 748.8 m² (8,060 ft²). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 65.6 °C (150 °F). Housing Material: Carbon Steel. Number of Plates: 407.

plate and frame heat exchanger Heat Transfer Surface Area: 3.2 m² (34 ft²). Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 121.1 °C (250 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 121.1 °C (250 °F).

SCHMIDT plate heat exchanger Volume: 0.3/0.2 liter (12) 36L stainless steel (1.44.01) plates. Heat Transfer Surface Area: 0.2 m² (2.2 ft²). Nozzle Schedule: - Openings: inlet 2-DN25, outlet 2-DN25. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 200 °C (392 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 200 °C (392 °F). Housing Material: Stainless Steel 316. Number of Plates: 12.

plate heat exchanger, pressure both side 10 bar @ 120 degrees C (31.9 & 31.9 liter) 1492kw, 316 stainless steel (1.4404) plates, carbon steel pressure plate and frame Heat Transfer Surface Area: 20.2 m² (217.4 ft²). Nozzle Schedule: openings : 4-100mm 316Ti stainless steel (1.4571). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 120 °C (248 °F). Housing Material: Carbon Steel. Number of Plates: 77.

Pass Arrangement: H.S.-1, C.S.-1 Heat Transfer Surface Area: 84.5 m² (910 ft²). Nozzle Schedule: Cold side inlet/outlet are 8", hot side inlet & outlet are 8". Six inch drain valve.. Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 93.3 °C (200 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 93.3 °C (200 °F). Housing Material: Carbon Steel. Number of Plates: 153.

Type: V60.SST.A carbon steel frame Heat Transfer Surface Area: 36.3 m² (390.7 ft²). Cold-side Pressure: 4 bar (58 psi). Cold-side Temperature: 130 °C (266 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 130 °C (266 °F). Housing Material: Carbon Steel. Number of Plates: 34.

Alfa Laval Plate Heat exchanger Process side rated 72.6 L, 3 Bar @ 75 degrees C; Service side rated 72.6L, 3 bar @ 95 degrees C. Heat Transfer Surface Area: 13.9 m² (150 ft²). Cold-side Pressure: 0.21 bar (3 psi). Cold-side Temperature: 35 °C (95 °F). Hot-side Pressure: 0.21 bar (3 psi). Hot-side Temperature: 23.9 °C (75 °F).

pack with CS frame, Tranter Superchanger plate Pack minimum 30.64 Pack Maximum 31.9. Inlets and outlets are 8". Heat Transfer Surface Area: 114.8 m² (1,236 ft²). Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 121.1 °C (250 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 121.1 °C (250 °F). Housing Material: Carbon Steel. Number of Plates: 194.

pack with CS shell Heat Transfer Surface Area: 84.5 m² (910 ft²). Nozzle Schedule: Pass arrangement H.S.-1, C.S.-1Inlets and outlets are 8". Drain is 6".. Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 93.3 °C (200 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 93.3 °C (200 °F). Housing Material: Carbon Steel. Number of Plates: 153.

192.2 liter volume Heat Transfer Surface Area: 76.9 m² (827.5 ft²). Nozzle Schedule: openings 4-140mm. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 80 °C (176 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 80 °C (176 °F). Housing Material: Carbon Steel. Number of Plates: 124.

Rated 150 PSI @ -20/+ 260 degrees F on process side, 150 PSI @ -20/+260 degrees F on service side Heat Transfer Surface Area: 48.3 m² (520 ft²). Nozzle Schedule: - Openings: 2-6" process side, 2-6" service side. Cold-side Pressure: 10.3 bar (150 psi). Cold-side Temperature: 126.7 °C (260 °F). Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 126.7 °C (260 °F).

Heat Transfer Surface Area: 13 m² (140 ft²). Nozzle Schedule: Openings: process side 2-2"; service side 2-2".. Number of Plates: 38.

Heat Transfer Surface Area: 20.9 m² (225 ft²). Nozzle Schedule: Opening sizes: service 2-4"; product 2-4". Number of Plates: 150.

plate heat exchanger frame only. Type: R405 4.1 sq ft per plate. carbon frame Frame opens to 5' clearance. Heat Transfer Surface Area: 42 m² (452.1 ft²). Nozzle Schedule: Openings: 2-4" inlets and 2-4" outlets.. Housing Material: Carbon Steel. Number of Plates: 110.

Heat Transfer Surface Area: 18.2 m² (196 ft²). Nozzle Schedule: 4-3" on one end. Cold-side Pressure: 6.9 bar (100 psi). Cold-side Temperature: 93.3 °C (200 °F). Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 93.3 °C (200 °F). Number of Plates: 47.

Unit w/cylindrical shell (23) 316SS plates (cylindrical, vert) inside shell Heat Transfer Surface Area: 0.8 m² (8.6 ft²). Nozzle Schedule: Openings: tube side 2-2"; shell 2-3". Cold-side Pressure: 16 bar (232.1 psi). Cold-side Temperature: 150 °C (302 °F). Hot-side Pressure: 16 bar (232.1 psi). Hot-side Temperature: 150 °C (302 °F). Number of Plates: 23.

unit w/CS cylindrical shell, bolt dish top, weld flat btm 316SS cylindrical plates inside shell (vertical plates) Heat Transfer Surface Area: 0.8 m² (8.6 ft²). Nozzle Schedule: openings: tube side 2-2"; shell 2-3" . Cold-side Pressure: 25 bar (362.6 psi). Cold-side Temperature: 200 °C (392 °F). Hot-side Pressure: 25 bar (362.6 psi). Hot-side Temperature: 200 °C (392 °F). Number of Plates: 23.

Heat Transfer Surface Area: 339 m² (3,649 ft²). Nozzle Schedule: (4) 7 1/2" diameter nozzles.. Number of Plates: 270.

Heat Transfer Surface Area: 20.9 m² (225 ft²). Number of Plates: 150.

Type M10B - gasketed 316SS plates Overall dimensions: 1084mm H x 470mm W, bottom nozzels are x 215 mm from base. (42" H x 18" W) Heat Transfer Surface Area: 102.2 m² (1,100 ft²). Nozzle Schedule: Openings: (4) 100MM, 150 psi flanged connections. . Housing Material: Carbon Steel.

plate heat exchanger Heat Transfer Surface Area: 19.2 m² (206.7 ft²). Nozzle Schedule: - Opening sizes: 4-65mm, 2-65mm, 2-65mm on sides.. Cold-side Pressure: 8 bar (116 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 8 bar (116 psi). Hot-side Temperature: 100 °C (212 °F). Number of Plates: 32.

2-pass both sides Heat Transfer Surface Area: 8.1 m² (87.4 ft²). Nozzle Schedule: - Openings: 4-100mm. Cold-side Pressure: 4 bar (58 psi). Cold-side Temperature: 24.9 °C (76.8 °F). Hot-side Pressure: 4 bar (58 psi). Hot-side Temperature: -1.11 °C (30 °F). Number of Plates: 31.

316 ss side 1 12,000 ltr/hr, side 2 6000 ltr/hr Heat Transfer Surface Area: 22.4 m² (241.5 ft²). Nozzle Schedule: Openings: 4-75mm nozzles. Cold-side Pressure: 10.3 bar (150 psi). Hot-side Pressure: 10.3 bar (150 psi). Number of Plates: 34.

2500 ltr/hr Heat Transfer Surface Area: 4 m² (42.6 ft²). Nozzle Schedule: Openings: process side 4-40mm; service side 2-40mm. Cold-side Pressure: 5 bar (72.5 psi). Hot-side Pressure: 5 bar (72.5 psi). Number of Plates: 43.

• Type: P14RB Heat Transfer Surface Area: 25.8 m² (277.7 ft²). Nozzle Schedule: W/2-3" (75mm) nozzles on top of one endplate and 2-3" (75mm) nozzles on btm of other endplate.. Hot-side Pressure: 6 bar (87 psi). Number of Plates: 38.

983 sq ft 3.45 sq ft per plate. Rated 21 Kg/CM sq (298 psi) both sides. Heat Transfer Surface Area: 91.3 m² (983 ft²). Nozzle Schedule: Unit has 2-4" inlets, 2-4" outlets. . Cold-side Pressure: 20.5 bar (298 psi). Hot-side Pressure: 20.5 bar (298 psi). Number of Plates: 285.

With overhead shifting bar for plate removal. Heat Transfer Surface Area: 92.2 m² (992 ft²). Nozzle Schedule: Nozzles: 4-8" on one end. Cold-side Pressure: 8 bar (116 psi). Hot-side Pressure: 8 bar (116 psi). Number of Plates: 124.

Rated 145 PSI @-34/+140 degrees F on process side, 145 PSI @ -34/+ 140 degrees F on service side. Heat Transfer Surface Area: 8.6 m² (93 ft²). Nozzle Schedule: Openings: 2-3" service side, 2-2" process side.. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 60 °C (140 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 60 °C (140 °F).

Heat Transfer Surface Area: 16.8 m² (180.8 ft²). Nozzle Schedule: - Openings: - One side: 2-100mm, 2-75mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 120 °C (248 °F). Number of Plates: 59.

Hot water flow rate: 50,000 liter/hr Plate assembly: (4) sections (61,113,49,49) Designed throughput: 20,000 liters/hr (milk) Temperature range: 5 degree C - 74 degrees C to minus 4 degrees C Hot water flow rate: 50,000 liter/hr Steam flow rate: 320 Kg/hr @ 1.0-1.5 Kp/sq cm Cold water flow rate: 50,000 liter/hr @ 1 degree C Heat Transfer Surface Area: 134.6 m² (1,449 ft²). Number of Plates: 272.

Heat Transfer Surface Area: 148.3 m² (1,596 ft²). Nozzle Schedule: Openings: 4-4". Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 103.3 °C (218 °F). Number of Plates: 152.

Welded plate heat exchanger type with 316TiSS wetted parts horizontal design reference number 6121B Process side rated 2 bar @ 150 °C design pressure, 0.5 bar 19 dm3 capacity; service side rated 2 bar @ 100 °C, 43 dm3 capacity. All wetted parts are material Z2CND 17-12 France standard, (3156TiSS). Empty weight 410 Kg. Heat Transfer Surface Area: 5.4 m² (58 ft²). Length: 1,935 mm (76.2 in). Nozzle Schedule: Openings include service side (2) 50mm, process side (1) 50mm, (1) 80mm. . Cold-side Pressure: 2 bar (29 psi). Cold-side Temperature: 100 °C (212 °F). Hot-side Pressure: 2 bar (29 psi). Hot-side Temperature: 150 °C (302 °F). Housing Material: Carbon Steel.

Heat Transfer Surface Area: 27 m² (290.6 ft²). Nozzle Schedule: - Openings: 4 x 100mm. Hot-side Pressure: 6.9 bar (100.1 psi). Number of Plates: 63.

Flow rate: 30,000 liter/hr Cooling rate: water from 100 deg C to 0 deg C Rated 90 psi (6 bar) Heat Transfer Surface Area: 6.5 m² (70 ft²). Nozzle Schedule: - Openings: 4- 65mm. Hot-side Pressure: 6.2 bar (90 psi). Number of Plates: 41.

15 m3l/h 300mm x 860mm plates Heat Transfer Surface Area: 6 m² (64.6 ft²). Nozzle Schedule: Openings: 4-50mm. Hot-side Pressure: 5 bar (72.5 psi). Hot-side Temperature: 100 °C (212 °F). Number of Plates: 30.

Heat Transfer Surface Area: 10.8 m² (116 ft²). Nozzle Schedule: Openings: 4-100mm. . Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 50 °C (122 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 50 °C (122 °F). Number of Plates: 20.

Each plate rated 4.1 sq ft Heat Transfer Surface Area: 40.5 m² (436 ft²). Nozzle Schedule: Openings: 2-4" inlets and 2-4" outlets. . Cold-side Pressure: 10.3 bar (150 psi). Hot-side Pressure: 10.3 bar (150 psi). Number of Plates: 106.

Heat Transfer Surface Area: 9.1 m² (97.5 ft²). Nozzle Schedule: - Inlet/Outlet Size: 2" (on both hot and cold sides). Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 110 °C (230 °F). Number of Plates: 75.

2-pass both sides Heat Transfer Surface Area: 8.1 m² (87.4 ft²). Nozzle Schedule: 4-100mm openings,. Cold-side Pressure: 4 bar (58 psi). Cold-side Temperature: 24.9 °C (76.8 °F). Hot-side Pressure: 4 bar (58 psi). Hot-side Temperature: 30 °C (86 °F). Number of Plates: 31.

Plate dimensions: 300mm x 850mm Flow rate: 2500 l/hr Rated 5 bar @ 65 deg C to 25 deg C.2500 l/hr. 2500 l/hr. Heat Transfer Surface Area: 10 m² (107.6 ft²). Nozzle Schedule: Openings: 6-35mm.. Hot-side Pressure: 5 bar (72.5 psi). Hot-side Temperature: 65 °C (149 °F). Number of Plates: 40.

Plate size: 4.1 sq ft each Heat Transfer Surface Area: 40.5 m² (436 ft²). Nozzle Schedule: Openings: 2-4" inlets and 2-4" outlets.. Cold-side Pressure: 10.3 bar (150 psi). Hot-side Pressure: 10.3 bar (150 psi). Number of Plates: 106.

Heat Transfer Surface Area: 148.3 m² (1,596 ft²). Nozzle Schedule: - Openings: 4-4". Hot-side Pressure: 10.3 bar (150 psi). Hot-side Temperature: 103.3 °C (218 °F). Number of Plates: 152.

304SS plates Max working pressure 100 psi @ 200 deg F Heat Transfer Surface Area: 203.1 m² (2,186 ft²). Nozzle Schedule: 2-10" inlets, 2-10" outlets. . Hot-side Pressure: 6.9 bar (100 psi). Hot-side Temperature: 93.3 °C (200 °F). Number of Plates: 241.

Ti s/steel plates Passes: 2-pass both sides Heat Transfer Surface Area: 8.1 m² (87.4 ft²). Nozzle Schedule: 4-100mm openings,. Cold-side Pressure: 4 bar (58 psi). Cold-side Temperature: 24.9 °C (76.8 °F). Hot-side Pressure: 4 bar (58 psi). Hot-side Temperature: 30 °C (86 °F). Number of Plates: 31.

• Plate dimensions: (23) 300mm x 900mm Heat Transfer Surface Area: 5.5 m² (58.8 ft²). Nozzle Schedule: - Openings: t-75mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 120 °C (248 °F). Hot-side Pressure: 6 bar (87 psi). Hot-side Temperature: 120 °C (248 °F). Number of Plates: 23.

carbon steel pressure plate and frame, Heat Transfer Surface Area: 6 m² (64.6 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 160 °C (320 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 160 °C (320 °F). Number of Plates: 43.

carbon steel pressure plates and frame, Heat Transfer Surface Area: 202.7 m² (2,182 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 90 °C (194 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 90 °C (194 °F). Number of Plates: 327.

Comabloc heat exchanger Rated 145 PSI @ -32?+145 degrees F on the process side, 145 PSI @-32/+365 degrees F on service side The all-welded plate pack does away with all gaskets between plates, and makes it possible to operate with a wide range of aggressive media and at high temperatures and pressures. Heat Transfer Surface Area: 8.6 m² (93 ft²). Nozzle Schedule: Openings: 2-3" process side, 2-2" service side. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 185 °C (365 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 62.8 °C (145 °F).

carbon steel pressure plates and frame, Heat Transfer Surface Area: 193.8 m² (2,086 ft²). Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 90 °C (194 °F). Hot-side Pressure: 10 bar (145 psi). Hot-side Temperature: 90 °C (194 °F). Number of Plates: 323.

carbon steel pressure plates and frame, Heat Transfer Surface Area: 108.8 m² (1,171 ft²). Cold-side Pressure: 10 bar (145 psi). Hot-side Pressure: 10 bar (145 psi). Number of Plates: 340.

carbon steel pressure plates and frame, Heat Transfer Surface Area: 21.1 m² (227.1 ft²). Cold-side Pressure: 2.4 bar (34.8 psi). Cold-side Temperature: 90 °C (194 °F). Hot-side Pressure: 5 bar (72.5 psi). Hot-side Temperature: 90 °C (194 °F). Number of Plates: 96.

• Plate dimensions: (48) 24" (800mm) x 10" (250mm)
• Cooling capacity: 90 gal/min (20 cu meter/hr)
• Temperature range: 32 deg F to 26 deg F (0 deg C to -3 deg C) Heat Transfer Surface Area: 8.1 m² (87 ft²). Number of Plates: 48.

Heat Transfer Surface Area: 32.1 m² (346 ft²). Nozzle Schedule: Has 4-6" openings. . Number of Plates: 44.

Type Sigma 20. Cooling brine from 15 deg C to 5 deg C. 6,000 liter/hr. Heat Transfer Surface Area: 5 m² (53.8 ft²). Nozzle Schedule: 4-1 1/2" (35mm) openings.. Hot-side Pressure: 6.2 bar (90 psi). Number of Plates: 32.

316 stainless steel plates Heat Transfer Surface Area: 42 m² (452.1 ft²). Nozzle Schedule: 4-50mm openings,. Number of Plates: 70.

spare plate pack for Heat exchanger IPP # 216118 ( EQ 4161) 59 plates at 33.36 sq.ft. per plate Heat Transfer Surface Area: 182.8 m² (1,968 ft²). Number of Plates: 59.
