Jacket conical screw mixer/dryer with top mounted filter, screw 7 bar @ 150 degrees C (18.5 liter), single internal 316L (1.4404) stainless steel screw which is cored for steam heating, screw bottom driven by 11kw 3/50/380 volt 1500 rpm Eex motor, carriage motor 1.1 kw, 3/50/380 volt 1500 rpm Ex motor, bottom discharge vale driven by 0.75kw, 3/50/380 volt 1400 rpm Ex motor, dished top with a 5.5 square meter 316L (1.4404) stainless steel jacketed reverse jet filter, manufactured by Kilsch Apparatebau Gmbh, fabrik #2184/2, pressure -1/2 bar @ 170 degrees C (750 liter), bolt dished top, (4) jets, TUV certified
Type: Dryer-Nauta
Manufacturer: Krauss Maffei
Model: TMT 20/300
Condition: Used
Material: Stainless Steel Austenitic
Capacity: 20,000 L (5,283 gallons)
Vessel Pressure: 2 bar (29 psi)
20 CuM, (704 CuFt) Krauss Maffei/Titus Nauta type Blender/Dryer Internal has a 4 micron polished finish The Dryer has an internal rotating scew agitator, rated speed is 10 to 100 rpm Screw carriage rated speed is rated .035-.35 rpm Vessel diameter is 3900mm External bottom mounted screw drive. Pneumatically activated product discharge valve Unit has a top mounted 6 sqM 316Ti jacketed bag filter
Vessel Temperature: 150 °C (302 °F). Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 150 °C (302 °F). Dust Collection: Yes.
Type: Dryer-Nauta
Manufacturer: Bauer Mainz
Model: T710C
Condition: Used
Material: Stainless Steel 316
Clad: Yes
Capacity: 10,000 L (2,642 gallons)
Vessel Pressure: 3.2 bar (46.4 psi)
single stainless steel screw screw bottom driven, dished top with a 26 square meter 316Ti (1.4571) stainless steel reverse jet filter pressure -1/3 bar @ 165 degrees C, bolt dished top, (12) jets TUV certified, CE marked insulated and cladd,
Vessel Temperature: 250 °C (482 °F). Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 165 °C (329 °F).
Type: Dryer-Nauta
Manufacturer: Engelsmann AG
Condition: Used
Material: Stainless Steel 316
Clad: Yes
Capacity: 10,000 L (2,642 gallons)
Vessel Pressure: 3.2 bar (46.4 psi)
pressure -1/3.2 bar @ 250 degrees C single stainless steel screw, screw bottom driven dished top with a 316Ti (1.4571) stainless steel reverse jet filter, pressure -1/3 bar @ 165 degrees C (1220 liter), bolt dished top, (6) jets, TUV certified, CE marked fully insulated and cladd,
Vessel Temperature: 165 °C (329 °F). Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 165 °C (329 °F).
Type: Dryer-Nauta
Manufacturer: Vrieco Nauta
Model: 20 VB-S
Condition: Unused
Material: Stainless Steel 316
Capacity: 2,000 L (528.3 gallons)
Vessel Pressure: 6 bar (87 psi)
Vessel Temperature: 100 °C (212 °F). Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 100 °C (212 °F).
