Alloy 926 (1.4529) stainless steel
Ex motor with an electric converter 27kw, 3/50/400 volt 100-1000 rpm,
Thermosyphon/plow driven by an 20 liter hydraulic powerpack, driven by 1.5kw, 3/50/380 volt, 1415 rpm
Ex motor, cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, feed pipe with nozzles.
Type: Centrifuge-Basket
Subtype: Manual Discharge-Top
Manufacturer: Krauss Maffei
Model: VZO 125/3.2C
Condition: Used
Material: Alloy 926
Basket Diameter: 1,250 mm (49.2 in)
Basket Depth: 800 mm (31.5 in)
Alloy 926 (1.4529) stainless steel
Ex motor with an electric converter 27kw, 3/50/400 volt 100-1000 rpm,
Thermosyphon/plow driven by an 20 liter hydraulic powerpack, driven by 1.5kw, 3/50/380 volt, 1415 rpm
Ex motor, cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, feed pipe with nozzles.
Filtration Area: 3.2 m² (34.4 ft²). Motor Power: 30 kW (40.2 HP). Speed-RPM Maximum: 950. Load Weight: 606 kg (1,336 lb). Gas Tight: Yes.
Type: Centrifuge-Basket
Subtype: Manual Discharge-Top
Manufacturer: Krauss Maffei
Model: VZO 125/3.2C
Condition: Used
Material: Alloy 926
Basket Diameter: 1,250 mm (49.2 in)
Basket Depth: 800 mm (31.5 in)
Alloy 926 (1.4529) stainless steel
Ex motor with an electric converter 27kw, 3/50/400 volt 100-1000 rpm,
Thermosyphon/plow driven by an 20 liter hydraulic powerpack, driven by 1.5kw, 3/50/380 volt, 1415 rpm
Ex motor, cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, feed pipe with nozzles,
Filtration Area: 3.2 m² (34.4 ft²). Motor Power: 30 kW (40.2 HP). Speed-RPM Maximum: 950. Load Weight: 606 kg (1,336 lb). Gas Tight: Yes.
Type: Centrifuge-Basket
Subtype: Manual Discharge-Top
Manufacturer: Krauss Maffei
Model: DZU-125/3.2
Condition: Used
Material: Rubberlined
Basket Diameter: 1,250 mm (49.2 in)
Basket Depth: 800 mm (31.5 in)
top load bottom discharge
machine #9600
12mm thick basket
min speed 80 rpm
EX motor
Hastelloy C feed pipe
Hastelloy C cake gauge
Hastelloy wash pipe
rubber lined single motion
hydraulic driven plow
with a Hastelloy C removeable blade
driven by a hydraulic powerpack
with a 1.5 kw, 3/50/500 volt, 1415 rpm EXd3nG5 motor, local electric panel
Filtration Area: 3.2 m² (34.4 ft²). Motor Power: 45 kW (60.3 HP). Speed-RPM Maximum: 850. Load Weight: 500 kg (1,102 lb). Controls: Yes.
Type: Centrifuge-Basket
Subtype: Manual Discharge-Top
Manufacturer: Krauss Maffei
Model: VZO 125/3.2
Condition: Used
Material: Stainless Steel 316
Basket Diameter: 1,250 mm (49.2 in)
Basket Depth: 800 mm (31.5 in)
gas tight design (0.5 bar overpressure)
pressure -1/2 bar @ 135 degrees C,
12mm thick basket
3/50/380-660 volt
cake is discharged via a pneumatic thermosyphon peeling pipe/plow and also pressurised gas is introduced into the centrifuge which enables the solids to discharge upwards, Thermosyphon driven by its own powerpack with a 1.5kw, 3/50/380 volt, 1415 rpm EXde11CT4 motor,
feed pipe, wash pipe with spray nozzles
Filtration Area: 3.2 m² (34.4 ft²). Motor Power: 30 kW (40.2 HP). Speed-RPM Maximum: 950. Load Weight: 614 kg (1,354 lb). Gas Tight: Yes.
