Documentation shows Mills but we did not get some of them. With spare product containers. (read below) 60 kg Explosion shock resistant fluid bed dryer. Designed for cGMP production, it is a contained system, and can be used for other process’ such as food agglomeration and drying Model - MP2/3-K2-F1/2 Rated for Maximum absolute pre pressure of 11 bar and Maximum explosion over pressure of 12 bar Total volume 610 liters typical working volume is 18-160 liters based on the allowable product density of 1500 kg/m This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place With wet and dry loading ports, internal lighting, and sample ports Designed for liquid/binder addition, it includes the Peristaltic transfer pump. This dryer is part of a contained system, product never reaches outside the unit. It is also integrated to work with products upstream and downstream. Designed for easy and quick cleaning and changeovers, the clean in place and all the operations are completely automated, and can be controlled at a local operator station Air handling is achieved with a custom manufactured unit by ZAir, Type SKG-4,2 507-68273-1 Manufactured of 304 SS construction, it’s rated for 130-670 m3/Hr. at 20-80 degrees C This unit handles all the air heating, cooling, and humification duties The Main fan is driven by a 12.7 kW AC motor, and it also has a HEPA filter This unit is complete with all filters, and accessories High shear granulator available (IPP Stock # 233967. This unit also has spare product containers. Product containers are FBP 07304A.FBP101, # 001, built 2019, with Product container trolly. FBP 07304A.FBP101, # 002, built 2019, with Product container trolly. FBP 07304A.FBP101, # 003, built 2019, with Product container trolly Unit comes with one product container, all other additional equipment is available at an additional cost
Type: Dryer-Fluid Bed
Manufacturer: GEA
Model: MP 4
Condition: Unused
Material: Stainless Steel 316L
Capacity: 280 L (74 gallons)
Pressure: 11 bar (159.5 psi)
Note: Drawings show Mills, we did not get some of them. Suitable for installation in Hazardous areas.
Typical working volume is 30-225 liters based on the allowable product density of 1500 kg/m
This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place
With wet and dry loading ports, internal lighting, and sample ports
Air handling is custom manufactured by ZAir, Type SKG-4
Manufactured of 316 SS construction
This unit is complete with all filters, and accessories
High shear granulator (IPP Stock # 233969) is available at additional cost. 100 kg
Temperature: 100 °C (212 °F). Clean in Place: Yes. Bowl Diameter: 900 mm (35.4 in). Orientation: Vertical. Product Density: 1,500 m3 (52,972 ft3). Operational Mode: Batch. Dust Collection: Yes. Explosion-Shock Resistant: Yes.
Type: Dryer-Fluid Bed
Manufacturer: Calmic (William Boulton)
Condition: Used
Material: Stainless Steel 316
Capacity: 500 L (132.1 gallons)
Bowl Diameter: 1,219 mm (48 in)
200 Kg polished 316 stainless steel bin with agitator dryer complete with steam heater and fan steam heater battery manufactured by Thermo Eng serial # 82347 test pressure 42 kg/square meter fan manufactured by Fan Systems, serial # 17162/1 belt driven by flameproof motor
Bowl Height: 431.8 mm (17 in). Product Density: 0.5 m3 (17.7 ft3).
Type: Dryer-Fluid Bed
Manufacturer: Calmic (William Boulton)
Model: 12874
Condition: Used
Material: Stainless Steel 316
Bowl Diameter: 609.6 mm (24 in)
Bowl Height: 330.2 mm (13 in)
25 Kg fluid bed dryer with steam heated jacket/battery flameproof motor with (1) 24" diameter x 13" deep bin Complete with socks, temperature gauge and bag vinch (manual)
Type: Dryer-Fluid Bed
Manufacturer: Arthur White
Model: AWS
Condition: Used
Material: Stainless Steel 316
Capacity: 100 L (26.4 gallons)
Pressure: 5.5 bar (80 psi)
50 Kg With 2 stainless steel bins on wheels with Davidson "M" Series fan non-flameproof motor Unit complete with bag shaker, damper pulsator, temperature gauge and socks Dryer housing is carbon steel With on/off switch Unit rated @ 100-200 lb/hr.
Temperature: 130 °C (266 °F). Bowl Diameter: 609.6 mm (24 in). Bowl Height: 355.6 mm (14 in). Orientation: Vertical. Operational Mode: Batch.
