Stainless Steel 316L Alfa Laval SHE 111.V Spiral Heat Exchanger - IPP# 242709

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Model: SHE 111.V

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 19.3 m² (207.7 ft²)

Shell Pressure: 8 bar (116 psi)

• design pressure process side -1/6 barg @ -15/185 degrees C (190 liter),
• service side 8 barg @ -15/185 degrees C (130 liter),
• spacing process side 14, service 8,
• design code: ASME VIII DIV 1 1990

Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 670 mm (26.4 in). Head Material: Stainless Steel 316L. Length: 1,000 mm (39.4 in). Nozzle Schedule: openings process side: 1-250mm, 1-75mm, 1-50mm, service side: 2-75mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 185 °C (365 °F). Hot-side Pressure: 8 bar (116 psi). Hot-side Temperature: 185 °C (365 °F). Spiral Material: Stainless Steel 316L.

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Model: SHE 111.V

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 19.3 m² (207.7 ft²)

Shell Pressure: 8 bar (116 psi)

• design pressure process side -1/6 barg @ -15/185 degrees C (190 liter),
• service side 8 barg @ -15/185 degrees C (130 liter),
• 670mm diameter x 1m cylindrical height,
• spacing process side 14, service 8,
• design code: ASME VIII DIV 1 1990

Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 670 mm (26.4 in). Head Material: Stainless Steel 316L. Length: 1,000 mm (39.4 in). Nozzle Schedule: process side: 1-250mm, 1-75mm, 1-50mm, service side: 2-75mm, . Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 185 °C (365 °F). Hot-side Pressure: 8 bar (116 psi). Hot-side Temperature: 185 °C (365 °F). Spiral Material: Stainless Steel 316L.

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 4 m² (43.1 ft²)

Shell Pressure: 4 bar (58 psi)

(2) 300mm high cone sections,

Shell Material: Stainless Steel 316L. Head Material: Stainless Steel 316L. Length: 300 mm (11.8 in). Nozzle Schedule: openings: 2-200mm, 3-50mm, 1-15mm,. Cold-side Pressure: 1 bar (14.5 psi). Spiral Material: Stainless Steel 316L.

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Model: SHE IV

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 2.8 m² (30.1 ft²)

Shell Pressure: 8 bar (116 psi)

• pressure side A: -1/6 barg @ -29/185 degrees C,
• side B: -1/8 barg @ -29/185 degrees C,
• spacing side A: 6 (23 liter), side B: 6 (17 liter)
• design code: ASME VIII DIV 1 Edition 1992,

Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 455 mm (17.9 in). Head Material: Stainless Steel 316L. Length: 250 mm (9.8 in). Nozzle Schedule: side A: 1-100mm, 1-75mm, side B: 3-50mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 185 °C (365 °F). Hot-side Pressure: 8 bar (116 psi). Hot-side Temperature: 185 °C (365 °F). Spiral Material: Stainless Steel 316L.
