Glasslined Cannon Tank - IPP# 242818

Type: Tank

Manufacturer: Cannon

Condition: Used

Material: Glasslined

Capacity (Design): 6,300 L (1,650 gallons)

Orientation: Vertical

• design pressure internal -1/3.5 barg @ -25/170 degrees C,
• jacket -1/6 barg @ -25/185 degrees C,
• design code: BS5500 1991 CAT 2

With (1) PTFE lined centrifugal pump, manufactured by Richter Chemie-Technik, type PCK/F 32-160, serial #916285/10/4, 2900 rpm, 165mm diameter impellor, mechanical seal, driven by 7.5kW, 3/50/415 volt, 2890 rpm EEx de IIB T4 IP55 motor, mounted on a baseplate,

Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 170 °C (338 °F). Does it have Agitation ?: Yes. Jacket Type: Standard. Jacket Material: Carbon Steel. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 185 °C (365 °F). Vacuum: Yes. Support: Legs.

Type: Tank

Manufacturer: Cannon

Condition: Used

Material: Glasslined

Capacity (Design): 6,300 L (1,650 gallons)

Orientation: Vertical

• design pressure 3.5 bar + full vacuum @ -25/170 degrees C,
• design code BS5500 1991 CAT 2,

With PTFE lined centrifugal pump manufactured by Richter, type PCK/F 32-190, serial #E927593/2/2, 2900 rpm, 165mm diameter impellor, driven by 7.5kW, 3/50/415 volt, 2870 rpm, EEx de IIB T4 IP55 motor, mechanical seal, mounted on a baseplate,

Diameter: 2,000 mm (78.7 in). Straight-side Length: 2,000 mm (78.7 in). Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 170 °C (338 °F). Vacuum: Yes. Support: Legs.

Type: Tank

Manufacturer: Cannon

Condition: Used

Material: Glasslined

Capacity (Design): 2,000 L (528 gallons)

Orientation: Vertical

• working capacity 1600 liter
• design pressure internal -1/3.5 bar @ -29/185 degrees C (2000 liter) ,
• jacket -1/10 barg @ -29/185 degrees C,
• design code: BS5500 CAT 2 1991 ISSUE 1

Diameter: 1,200 mm (46.3 in). Straight-side Length: 1,300 mm (50.7 in). Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 185 °C (365 °F). Jacket Type: Standard. Jacket Material: Carbon Steel. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 185 °C (365 °F). Vacuum: Yes. Support: Lugs.

Type: Tank

Manufacturer: Cannon

Condition: Used

Material: Glasslined

Capacity (Design): 1,900 L (496.6 gallons)

Orientation: Vertical

• 1600 liter working capacity,
• design pressure internal -1/3.5 barg @ -29/180 degrees C,
• jacket -1/10 barg @ -29-180 degrees C,
• design code BS5500 1991 CAT 2

Diameter: 1,200 mm (46.3 in). Straight-side Length: 1,300 mm (50.7 in). Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 180 °C (356 °F). Jacket Type: Standard. Jacket Material: Carbon Steel. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 180 °C (356 °F). Vacuum: Yes. Support: Lugs.
