316 stainless steel Glatt GPCG 300/500 Fluid Bed Dryer / Granulator - IPP# 247053

Type: Dryer-Fluid Bed

Manufacturer: Glatt

Model: WSG15

Condition: Used

Material: Stainless Steel 316

Capacity: 45 L (11.9 gallons)

Air Flow Rate: 750 m3/h (441.4 CFM)

15-30 Kg, 45 liter bowl capacity, 52000 K/hr steam heaters, compressed air @ 6 bar, Air warming range -10 degrees C to +70 degrees C, Electrics motor

Pressure: 3 bar (43.5 psi). Temperature: 70 °C (158 °F). Product Density: 0.04 m3 (1.41 ft3).

Type: Dryer-Fluid Bed

Manufacturer: Glatt

Model: WSG-CD 160

Condition: Used

Material: Stainless Steel 316

Capacity: 650 L (171.7 gallons)

Air Flow Rate: 100 m3/h (58.9 CFM)

• .600 liter 316/304 stainless steel Glatt fluid bed granulator dryer system, Project #8931/100.614/100.614, 1.4m diameter drying chamber, lower section has inflatable gasket, charging port with quick acting gate valve, filter housing with an installed product retaining filter, pressure relief openings with installed plates in the filter housing and following pressure relief ducts, (2) 316/304 stainless steel bowls, bowl dimensions 1.4m top diameter x 550mm straight side x 1m bottom diameter, bowls with bottom sieve mesh and trolley, bowl mesh max differential pressure 5000 Pa, system includes stainless steel bowl tipper, inlet air handling unit, Blower, Stahl Exicom control, control panel, dust filter and other ancillaries.

Pressure: 6 bar (87 psi). Temperature: 120 °C (248 °F). Bowl Diameter: 1,400 mm (55.1 in). Bowl Height: 550 mm (21.7 in). Particle Coating Ability: Yes with top spray & Tangential Spray options. Orientation: Vertical. Product Density: 1 m3 (35.3 ft3). Operational Mode: Batch. Dust Collection: Yes. Explosion-Shock Resistant: Yes.

Type: Dryer-Fluid Bed

Manufacturer: Glatt

Model: GPCG 5/9

Condition: Used

Material: Stainless Steel 316

Capacity: 25 L (6.6 gallons)

Air Flow Rate: 2,000 m3/h (1,200 CFM)

• Includes a 7" (9.6 Liter) and a 9"(18 liter) Wurtser Inserts for coating and processing flexibility.
• Stainless steel (highly polished) Glatt Fluid Bed Dryer system, chamber approx. 490mm diameter, (2) interchangeable bottom sections each with its own bowl, (1) stainless steel bowl 400mm top diameter x 270mm straight side x 270mm bottom diameter with trolley, (1) stainless steel bowl 350mm top diameter x 630mm straight side x 160mm bottom diameter with trolley, both bowls with internal filter meshes, internal hoist for filter bags, mounted on stainless steel legs, system includes : control panel with Eurotherm Chessel 6100 X 10 graphic chart recorder,

Pressure: 12 bar (174 psi). Temperature: 140 °C (284 °F). Bowl Diameter: 400 mm (15.7 in). Bowl Height: 270 mm (10.6 in). Particle Coating Ability: Yes. Orientation: Vertical. Operational Mode: Batch. HEPA Filtration: Yes. Dust Collection: Yes. Explosion-Shock Resistant: Yes.

Type: Dryer-Fluid Bed

Manufacturer: Glatt

Model: TFO 300-400

Condition: Used

Material: Stainless Steel 304

Capacity: 700 L (184.9 gallons)

Air Flow Rate: 14,000 m3/h (8,250 CFM)

load weight 300 kg special Vitamin-A-Pulver, with cyclones heater and cooler and de-dusting system Filter housing is 1.6m diamter, 2.5mm thick, with (59) bags, at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the hopper bottom. Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone. Bottom hopper mounted on 4 legs with wheels. With seperate heating cooling box, rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c. Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor

Pressure: 5 bar (72.5 psi). Bowl Diameter: 1,200 mm (46.9 in). Bowl Height: 1,300 mm (51.2 in). Orientation: Vertical.
