Stokes Blower - IPP# 85221

Type: Pump-Vacuum

Manufacturer: Stokes

Model: SHR2200

Condition: Used

Material: Carbon Steel

Air Flow: 594.7 m3/h (350 CFM)

Orientation: Horizontal

3-stage vac pump/jet system 1st stage: Stokes CS rotary vac pump, Mdl 310-41, SN 87533. W/4" suction and discharge opening. Powered by 2 HP, 3/50/60/208/230/460 volt, 2870/3480 rpm direct coupled motor. 2nd stage: Hick and Hargreaves CS vac jet, Order #CA13305. Nozzle throat dia 5.2mm. 3rd stage: Hicks water ring vac pump. SN H9126, Type SHR2200. 1470 rpm. 2" suction and discharge openings. W/solenoid operated inlet water piping and Burgess Manning water separator on discharge. Powered by 20 HP, 3/60/230/460 volt, 1760 rpm direct coupled TEFC motor.

Inlet Diameter: 101.6 mm (4 in). Outlet Diameter: 101.6 mm (4 in). Seal Type: Liquid Ring.

Type: Pump-Vacuum

Manufacturer: Stokes

Model: 212H-11

Condition: Used

Air Flow: 254.9 m3/h (150 CFM)

Orientation: Vertical

150 cfm @ 76mm, oil seal vac pump. Has oil mist separator.

Type: Pump-Vacuum

Manufacturer: Stokes

Model: TRH 0653C

Condition: Used

Material: Nickel

Air Flow: 280.3 m3/h (165 CFM)

Orientation: Horizontal

dual stage vacuum system. System consists of Stokes Eagle series dry pump model CDE-180 dry lobe vacuum pump with cooling jacket, all wetted surfaces electroless Nickel coated, With booster blower Stokes model 607-4Mv, Serial # 38750E0598 with all wetted surfaces electroless Nickel coated, driven by 10 hp 3/60/460V, 1755 rpm TEFC motor. Via "V" belt drive.
