Internal pressure 2 bar + full vacuum @ 200 degrees C; jacket 5 bar @ 200 degrees C Glass #59. 70-11.5 rpm, .87 KW, 3/50/500 volt non-flameproof motor. jacket 133 liter Unit with insulation on straight side and bottom dish.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler (Germany)
Model: DK
Condition: Used
Material: Glasslined
Capacity (Design): 757.1 L (200 gallons)
Internal Pressure: 10 bar (145 psi)
W/dip tube and thermo thymble. motor : 3/50/220/380 volt
Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Diameter: 1,000 mm (39.4 in). Straight Side Length: 1,100 mm (43.3 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler (Germany)
Model: E
Condition: Used
Material: Glasslined
Capacity (Design): 1,372 L (362.4 gallons)
Internal Pressure: 6 bar (87 psi)
Cont #30952 Glass #59. Equipped w/900mm dia Pfaudler VS5 agit drive w/3.5 KW, 3/50/380 volt, Agit 120 rpm output speed Designed to German TUV standards.
Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,200 mm (47.2 in). Straight Side Length: 1,260 mm (49.6 in).
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler (Germany)
Model: E
Condition: Used
Material: Glasslined
Capacity (Design): 2,157 L (569.8 gallons)
Internal Pressure: 3.9 bar (56.9 psi)
PLUG FREE 2000 liter
Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 15.6 bar (226.3 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,400 mm (55.1 in). Straight Side Length: 1,445 mm (56.9 in).
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler (Germany)
Model: DM
Condition: Used
Material: Glasslined
Capacity (Design): 757.1 L (200 gallons)
Internal Pressure: 10 bar (145 psi)
Type D Glass #59 W/varispeed pulleys 14.5-115 rpm, belt driven to 2.6 KW, 3/50/220/380 volt Designed to German TUV standards.
Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 6 °C (42.8 °F). Diameter: 1,000 mm (39.4 in). Straight Side Length: 1,100 mm (43.3 in).
