Filtration resistance due to cake build-up on stationary filter plates is limited to specific controlled thickness by the wiping action of the blades attached to rotating discs in each stage 12-stages, 24-rotating discs thru Dodge reducer, 5.5:1 ratio. W/control panel
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Artisan
Condition: Used
Material: Stainless Steel 316
Filtration Area: 6 m² (65 ft²)
Pressure: 27.6 bar (400 psi)
Filtration resistance due to cake build-up on stationary filter plates is limited to specific controlled thickness by the wiping action of the blades attached to rotating discs in each stage 12-stages, 24-rotating discs thru Dodge reducer, 5.5:1 ratio. W/control panel.
Temperature: 93.3 °C (200 °F).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Artisan
Condition: Used
Material: Stainless Steel 316
Filtration Area: 6 m² (65 ft²)
Pressure: 27.6 bar (400 psi)
continuous filter/washer Filtration resistance due to cake build-up on stationary filter plates is limited to specific controlled thickness by the wiping action of the blades attached to rotating discs in each stage 12-stages, 24-rotating discs thru Dodge reducer 5.5:1 ratio W/control panel
Temperature: 93.3 °C (200 °F).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Artisan
Model: 3
Condition: Used
Material: Stainless Steel 304
Filtration Area: 0.28 m² (3 ft²)
Diameter: 152.4 mm (6 in)
Continuous filter/washer Number of stationary filter plates: 11 Number of solid rotor discs with cake trimming vanes: 12 Drive: 3 HP adjustable speed drive Seal: Mechanical seal Sensor: Torque sensor Cake outlet size: 3/4" Filtrate outlet size: 2" Feed inlet size: 1/2" Mounting: On stand Control panel: Included 500 psi Pulsa diaphragm metering pump, Mdl 7120-S-E, driven by 1/2 HP motor.
Pressure: 27.6 bar (400 psi). Temperature: 93.3 °C (200 °F).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Seitz
Model: Radium RZ60A/6GCW
Condition: Used
Material: Stainless Steel 316
Filtration Area: 5.3 m² (56.5 ft²)
Orientation: Vertical
Internal (390 liter) Jacket (50 liter) (21) stainless steel plates 600mm Diameter, 750mm diameter x 1000mm straight side, Cake volume: 105 liter
Pressure: 6 bar (87 psi). Temperature: 133 °C (271.4 °F). Jacket: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 133 °C (271.4 °F).
