Centrifugal Compressor - IPP# 249441

Type: Compressor

Subtype: Centrifugal

Manufacturer: Atlas Copco

Model: 1616 6551 80

Condition: Unused

Material: Carbon Steel

Compressor Type: Centrifugal

Air end compressor head
Part # 1616 6551
GA55 GBD-
part # 2901-0844-00.

Type: Compressor

Subtype: Centrifugal

Manufacturer: Atlas Copco

Model: ZR160VSD

Material: Carbon Steel

Compressor Type: Centrifugal

Inlet Pressure: 0.965 bar (14 psi)

• Variable speed motor based on load.

Discharge Pressure: 8.62 bar (125 psi). Flow Rate: 1,628 m3/h (958 CFM). Oil Free: Yes.

Type: Compressor

Subtype: Centrifugal

Manufacturer: Clark

Model: 4M9-7

Condition: Used

Material: Carbon Steel

Compressor Type: Centrifugal

Inlet Pressure: 0.97 bar (14.1 psi)

Compound centrifugal compressor with seven impellers and labyrinth seals
Inlet pressure is 14.07 psia in the first section
and 40.4 psia in the second section

• Gas handled: air, with an average compressibility factor of 1.0
• First section discharge pressure: 42.9 psia
• Second section discharge pressure: 86 psia
• Discharge temperature: 373.5 degrees F (first section), 281.6 degrees F (second section)
• Pressure drop between sections: approximately 2 psi
• Operating speed: 5380 rpm
• Brake horsepower (BHP): 2662 (first section), 1748 (second section)
• Maximum continuous speed: 5,650 rpm
• First critical speed: 2,670 rpm
• Inlet sizes: 30" (up connection), 10" (up connection)
• Discharge sizes: 20" (both)
• Driven by: steam turbine (IPP# 212810) through a gear reducer (IPP# 212811)
• Lubrication: shares a common lubrication skid.

Discharge Pressure: 5.93 bar (86 psi). Flow Rate: 42,440 m3/h (24,979 CFM). Inlet Diameter: 762 mm (30 in). Speed (RPM): 5,650.

Type: Compressor

Subtype: Centrifugal

Manufacturer: Clark

Model: 2M8-6

Condition: Used

Material: Carbon Steel

Compressor Type: Rotary

Inlet Pressure: 0.97 bar (14.1 psi)

4,079 acfm
rotary air compressor
Direct driven by a steam turbine (IPP# 212810) through a gear reducer (IPP# 212811)
Pressure Suction 14.07
6400 rpm critical speed
12"" inlet X 10"" discharge
Nozzle orientation is up

Discharge Pressure: 33.8 bar (490 psi). Flow Rate: 6,930 m3/h (4,079 CFM). Inlet Diameter: 305 mm (12 in). Speed (RPM): 10,211.
