316 stainless agitated jacketed pressure Nutsche filter Filter volume 7200 liters Hydraulic racker lift driven by 0.75 KW, 3/50/500 volt motor. Packing gland on shaft
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Bertrams (Basel)
Condition: Used
Material: Stainless Steel 316
Filtration Area: 5.9 m² (64 ft²)
Diameter: 2,741 mm (107.9 in)
316 stainless steel agitated jacketed pressure Nutsche filter Filter volume 7200 liters Drive manufactured by Von Roll, Type CRG5 Hydraulic racker lift driven by 0.75 HP, 3/50/500 volt, 1450 rpm motor. Packing gland on shaft
Pressure: 2 bar (29 psi). Jacket: Yes. Jacket Type: Internal Pipe Coil. Jacket Pressure: 6 bar (87 psi).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Bertrams (Basel)
Condition: Used
Material: Stainless Steel 316
Filtration Area: 6 m² (64.6 ft²)
Diameter: 2,741 mm (107.9 in)
Filter volume 7200 liters Hydraulic agitator lift driven by 0.75 KW, 3/50/500 volt motor. Hydraulic agitator lift driven by 0.75 KW, 3/50/500 volt motor. Packing gland on shaft
Pressure: 2 bar (29 psi). Jacket: Yes. Jacket Pressure: 6 bar (87 psi).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Bertrams (Basel)
Condition: Used
Material: Stainless Steel 316
Filtration Area: 6 m² (64.6 ft²)
Diameter: 2,741 mm (107.9 in)
Vessel is 108" (2741mm) diameter x 39" (990mm) straight side, Filter volume 7200 liters Hydraulic agitator lift driven by 0.75 KW, 3/50/500 volt motor. Packing gland on shaft Unit designed for brick type filter stone (none with unit)
Pressure: 2 bar (29 psi). Jacket: Yes. Jacket MOC: Stainless Steel 316. Jacket Pressure: 6 bar (87 psi).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Rosenmund
Model: RPD 8-398-86
Condition: Used
Material: Stainless Steel 316
Filtration Area: 8 m² (86.1 ft²)
Diameter: 3,260 mm (128.3 in)
Codap85
center bottom discharge design
Includes hydraulic controls and vacuum pump skid.
316L stainless steel half pipe coil jacket on straight side cover with a shroud
jacket volume is 75 liters.
jacket -1/5 bar
Non-cored shaft.
Rated: internal pressure -1/3 bar
Designed for cake thickness 500mm.
Vessel is 13200liter volume
Includes hydraulic controls and vacuum pump skid
Pressure: 3 bar (43.5 psi). Temperature: 165 °C (329 °F). Jacket: Yes. Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 316. Jacket Pressure: 5 bar (72.5 psi). Jacket Temperature: 165 °C (329 °F).
