Type: Heat Exchanger
Subtype: Block
Manufacturer: Carbone
Model: GM8
Condition: Refurbished/Rebuilt
Material: Graphite
Heat Transfer Surface Area: 3 m² (32.3 ft²)
Orientation: Vertical
Shell Diameter: 400 mm (15.7 in). Length: 800 mm (31.5 in). Nozzle Schedule: Openings: service side 2-75mm; process side 2-125mm. Process Pressure: 6 bar (87 psi). Process Temperature: 165 °C (329 °F).
Type: Heat Exchanger
Subtype: Block
Manufacturer: Carbone
Model: PBC8DL-5PU-1-6
Condition: Used
Material: Graphite
Heat Transfer Surface Area: 5.8 m² (62.5 ft²)
Orientation: Vertical
cylindrical block tubes rated 100 psi & FV @ -20/+400 degrees F. 1 pass axial, 6 pass radial
Shell Pressure: 12.8 bar (185 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 381 mm (15 in). Length: 2,300 mm (90 in). Nozzle Schedule: Openings: Tube side 1-3", 1-2". Shell side 2-1 1/2", 1-2".. Process Pressure: 6.9 bar (100 psi). Process Temperature: 204.4 °C (400 °F).
Type: Heat Exchanger
Subtype: Block
Manufacturer: Carbone
Model: GM8
Condition: Refurbished/Rebuilt
Material: Graphite
Heat Transfer Surface Area: 3 m² (32.3 ft²)
Orientation: Vertical
Shell Pressure: 6 bar (87 psi). Shell Temperature: 165 °C (329 °F). Shell Diameter: 400 mm (15.7 in). Length: 800 mm (31.5 in). Nozzle Schedule: Openings: service side 2-75mm; process side 2-125mm. .
Type: Heat Exchanger
Subtype: Block
Manufacturer: Carbone
Model: CL36-4PU-1-5
Condition: Used
Orientation: Vertical
Vacuum: Yes
Polybloc Graphilor Design pressure rated for 100/100 internal pressure rated for rated for FV/350 psi at 350 degrees F Test pressure rated for FV100/100psi
