Welded plate heat exchanger type with 316TiSS wetted parts horizontal design reference number 6121B Process side rated 2 bar @ 150 °C design pressure, 0.5 bar 19 dm3 capacity; service side rated 2 bar @ 100 °C, 43 dm3 capacity. All wetted parts are material Z2CND 17-12 France standard, (3156TiSS). Empty weight 410 Kg.
Type: Heat Exchanger
Subtype: Plate and Frame
Manufacturer: Bariquand Platulaire Heat Exchanger
Model: DIXASP 1x16/1x15x2500x280
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 18 m² (194 ft²)
Nozzle Schedule: Openings: Service side (2) 150mm, process side (2) 50mm, (1) 200mm
welded plate heat exchanger with 316TiSS wetted parts horizontal design 0.7 bar working pressure 90 dm3 capacity 125 dm3 capacity All wetted parts are material Z2CND 17-12 France standard, (3156TiSS) The rectangular housing is 260 mm wide, 3200 mm long Empty weight 1200 Kg
Cold-side Pressure: 5 bar (72.5 psi). Cold-side Temperature: 50 °C (122 °F). Hot-side Pressure: 3 bar (43.5 psi). Hot-side Temperature: 150 °C (302 °F). Housing Material: Carbon Steel.
Type: Heat Exchanger
Subtype: Plate and Frame
Manufacturer: GEA Ahlborn GmbH Co KG/Germany
Model: N40
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 47.5 m² (512 ft²)
Cold-side Pressure: 12 bar (174 psi)
design BC-12 0.45 squaremeter heat exchange surface per plate, (plate package min 851mm, max 870mm), plate package is 868mm 321 (1.4541) stainless steel frame
Cold-side Temperature: 115 °C (239 °F). Hot-side Pressure: 12 bar (174 psi). Hot-side Temperature: 115 °C (239 °F). Housing Material: Stainless Steel 321. Number of Plates: 105.
Type: Heat Exchanger
Subtype: Plate and Frame
Manufacturer: Tranter
Model: GC-30NI*28
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 2.2 m² (23.8 ft²)
Nozzle Schedule: - Openings: 4-50mm
pressure side 1= -1/6 bar @ 170 deg C (2.9ltr) side 2= -1/6 bar @ 170 deg C (3.1ltr) test pressure both sides 10 bar c/steel frame
Housing Material: Carbon Steel. Number of Plates: 28.
Type: Heat Exchanger
Subtype: Plate and Frame
Manufacturer: Tranter
Model: GC-30NI*28
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 2.2 m² (23.8 ft²)
Nozzle Schedule: - Openings: 4-50mm
pressure side 1= -1/6 bar @ 170 deg C (2.9ltr) side 2= -1/6 bar @ 170 deg C (3.1ltr) test pressure both sides 10 bar c/steel frame
Housing Material: Carbon Steel. Number of Plates: 28.
