Name: 7,550 L (2,000 gallons) Stainless Steel 316 Batch-Type Agitated Reactor
Brand: Alloy Industries
SKU: 241046

Overview

Type:

Reactor

Subtype:

Batch-Type Agitated

Manufacturer:

Alloy Industries

Condition:

Used

Material:

Stainless Steel 316

Capacity (Design):

7,550 L (2,000 gallons)

Internal Finish:

Mill 2B

Body Only:

Yes

Pressure Vessel

Internal Pressure:

10.3 bar (150 psi)

Internal Full Vacuum:

Yes

Internal Temperature:

204.4 °C (400 °F)

Jacket/Internal Coil

Jacket Pressure:

10.3 bar (150 psi)

Jacket Temperature:

204.4 °C (400 °F)

Jacket Type:

Half Pipe/Limpet

Jacket Material of Construction:

Stainless Steel 304

Dimensions

Orientation:

Vertical

Diameter:

2,000 mm (78 in)

Straight Side Length:

2,150 mm (84 in)

Agitation System

Baffle Type:

Sidewall Mounted Straight Baffle

Baffle Details:

4 Internal side wall baffles

Heads

Top Head Type:

Elliptical

Top Head Material:

Stainless Steel 316

Bottom Head Type:

Elliptical

Bottom Head Material:

Stainless Steel 316

Other Specifications

CIP:

Yes

Manway:

Yes

Support Type:

Lugs

Inlets & Outlets

Nozzle Schedule:

18" Manway with davit assist and site glass, one 10" agitation nozzle (gusseted), Two 10 Nozzles, one 6" nozzle, eleven 4" nozzles, one 3" CBO, six 3" jacket nozzles. .

Stainless Steel 316 Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Condition: Used

Material: Stainless Steel 316

Capacity (Design): 757 L (200 gallons)

Jacket Material of Construction: Carbon Steel

With Lightnin, 1.5 hp mixer.
1" jacket supply and return lines.

Orientation: Vertical. Diameter: 965 mm (38 in). Straight Side Length: 914 mm (36 in). Support Type: Legs.

Stainless Steel 316 Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Cream City Boiler

Condition: Used

Material: Stainless Steel 316

Capacity (Design): 2,850 L (750 gallons)

Internal Pressure: 10.3 bar (150 psi)

Top Head 9/16", Bottom Head 1 3/16"; CS jacket 9/16" thick.Top mounted Lightnin drive, Model 85-5-40, 9.33 to 1 ratio,Direct coupled to a 5 HP 3/60/230/460 volt 1765 rpm motor, 180 RPM output.(4) blade pitched paddle mid shaft, 4 blade flat turbine on bottom, (4) baffles on side wall.

Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 1,700 mm (66 in). Straight Side Length: 1,450 mm (57 in). Support Type: Lugs.

565 L (149.3 gallons) Stainless Steel 316 Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Hanag AG

Condition: Used

Material: Stainless Steel 316

Capacity (Design): 565 L (149.3 gallons)

Internal Pressure: 6 bar (87 psi)

Total liter capacity is 565, 800 mm diameter x 975 mm tangent to tangent,

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 13 bar (188.5 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel 304. Body Only: Yes. Diameter: 800 mm (31.5 in). Straight Side Length: 975 mm (38.4 in). Support Type: Lugs.
