Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665

  • Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665 Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665
  • Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665 Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665
  • Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665
  • Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor - IPP# 242665
Overview
Reactor
Batch-Type Agitated
Pfaudler
CE10000
Used
Glasslined
11,750 L (3,100 gallons)
Glass Lined
Pressure Vessel
6 bar (87 psi)
Yes
200 °C (392 °F)
Jacket/Internal Coil
10 bar (145 psi)
200 °C (392 °F)
Standard
Carbon Steel
Dimensions
Vertical
2,350 mm (92.5 in)
1,950 mm (76.2 in)
Agitation System
Yes
Retreat Curve
Mechanical with Gas
Pfaudler agitator driven by 30kw, 3/50/400 volt, 1475 rpm IP55 EEx de IIC T4 ATEX motor via VSO 32/125 gearbox, shaft speed 9-90 rpm, 2-sets of 3-finger retreat curved agitators,
30 kW (40.2 HP)
30 kW (40.2 HP)
Beavertail
2-beavertail baffles
Heads
Dish
Glasslined
Dish
Glasslined
Other Specifications
Yes
Lugs
Inlets & Outlets
openings top: 1-500mm manway with 2-100mm sightglasses, 2-300mm, 7-200mm (2 with baffles), straight side jacket: 1-150mm, 3-50mm, 1-25mm, bottom: 1-150mm, 1-150mm (jacket), 2-80mm (jacket)
Additional Information
  • design pressure internal -1/6 barg @ -29/200 degrees C (11768 liter),
  • jacket -1/10 bar @ -29/200 degrees C (911 liter),
  • agitator driven by 30/35kw, 3/50-60/690-400/660-380/415-440 volt, 1475/1471/1477/1769 rpm IP55 EEx de IIC T4 ATEX motor via a reduction gearbox,
  • shaft speed 9-90 rpm,
  • glass type WWW9125,
  • CE 0038,
  • TUV,
  • design code: ASME VIII DIV 1, 2004 ANNEXE Z and essential safety requirements of PED/97/23/EC

Similar Equipment

Glasslined Pfaudler CE Batch-Type Agitated Reactor Body

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: CE10000

Condition: Used

Material: Glasslined

Capacity (Design): 11,750 L (3,100 gallons)

Internal Pressure: 6 bar (87 psi)

  • 10000 liter working capacity, z
  • design pressure internal -1/6 bar @ -29/200 degrees C (11768 liter),
  • jacket -1/10 bar @ -29/200 degrees C (911 liter),
  • glass type WWW 9125,
  • design code: ASME VIII DIV 1 2004 annex Z and essential safety requirements of PED/97/23/EC,

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Diameter: 2,350 mm (92.4 in). Straight Side Length: 1,950 mm (76.2 in). Support Type: Legs.

Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: CE10000

Condition: Used

Material: Glasslined

Capacity (Design): 11,750 L (3,100 gallons)

Internal Pressure: 6 bar (87 psi)

  • 10000 liter working capacity,
  • design pressure internal -1/6 barg @ -29/200 degrees C (11768 liter),
  • jacket -1/10 bar @ -29/200 degrees C (911 liter),
  • IP55 EEx de IIC T4 ATEX motor,
  • shaft speed 9-90 rpm,
  • CE 0038,
  • TUV,
  • glass type WWW9125,
  • design code: ASME VIII DIV 1, 2004 ANNEXE Z and essential safety requirements of PED/97/23/EC

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,350 mm (92.5 in). Straight Side Length: 1,950 mm (76.2 in). Support Type: Lugs.

Glasslined Pfaudler-Balfour CE Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: CE10000

Condition: Used

Material: Glasslined

Capacity (Design): 11,750 L (3,100 gallons)

Internal Pressure: 6 bar (87 psi)

  • 10000 liter working capacity,
  • design pressure internal -1/6 bar @ -29/200 degrees C (11768 liter),
  • jacket -1/10 bar @ -29/200 degrees C (911 liter),
  • EEx de IICT4 motor,
  • Hastelloy C22 axial flow turbine on shaft,
  • CE0038,
  • glass type WWW9125,
  • design code: ASME VIII DIV 1, 2004 ANNEXE Z and essential safety requirements of PED/97/23/EC,

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,350 mm (92.5 in). Straight Side Length: 1,950 mm (76.2 in). Support Type: Lugs.

Glasslined Pfaudler CE10000 Batch-Type Agitated Reactor

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: CE10000

Condition: Used

Material: Glasslined

Capacity (Design): 10,000 L (2,650 gallons)

Internal Pressure: 6 bar (87 psi)

  • design pressure internal -1/6 bar @ -29/200 degrees C,
  • jacket -1/10 bar @ -29/200 degrees C
  • glass type 9129,
  • driven by 30-35kW, 3/50-60/690-400/660-380/415-440 volt, 1475/1471/1477/1769 rpm ATEX EExd IIA/B T4 IP55
  • 9-90 rpm shaft speed,
  • white glass body, blue glass shaft and baffle
  • CE0038,
  • design code ASME VIII DIV 1 and essential safety requirements of PED/97/23/EC,

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,350 mm (92.5 in). Straight Side Length: 1,950 mm (76.2 in). Support Type: Lugs.
