Batch-Type Agitated Reactor - IPP# 247784

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: P

Condition: Re-glassed

Material: Glasslined

Capacity (Design): 37.9 L (10 gallons)

Internal Pressure: 1.72 bar (25 psi)

Reglassed at UGE facility 105 psi w/full vac int. Glass #59.

Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Diameter: 355.6 mm (14 in). Straight Side Length: 457.2 mm (18 in). Support Type: Legs.

Type: Reactor

Subtype: Batch-Type Agitated

Condition: Used

Material: Stainless Steel 316

Capacity (Design): 757 L (200 gallons)

Jacket Material of Construction: Carbon Steel

• With Lightnin, 1.5 hp mixer.
• 1" jacket supply and return lines.

Orientation: Vertical. Diameter: 965 mm (38 in). Straight Side Length: 914 mm (36 in). Support Type: Legs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Brown Hutchinson, Inc.

Condition: Used

Material: Stainless Steel 304

Capacity (Design): 1,050 L (275 gallons)

Internal Pressure: 3.4 bar (50 psi)

• Bottom outlets, 1.5" center bottom, two 0.5" and one 1"

Internal Full Vacuum: Yes. Jacket Pressure: 3.4 bar (50 psi). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 813 mm (32 in). Straight Side Length: 1,950 mm (76 in). Support Type: Lugs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: DeDietrich

Model: CSA

Condition: New

Material: Glasslined

Capacity (Design): 2,850 L (750 gallons)

Internal Pressure: 6.9 bar (100 psi)

Hemi-coil two circuit, two zone split pipe coil jacket rated 450 psig @ 500 degress F, -20 deg F @ 450 psig.

Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 31 bar (450 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Orientation: Vertical. Diameter: 1,500 mm (60 in). Straight Side Length: 1,200 mm (48 in). Support Type: Lugs.
