Glasslined Schwelm RITC Batch-Type Agitated Reactor - IPP# 89369

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Schwelm

Condition: Used

Material: Glasslined

Capacity (Design): 4,380 L (1,157 gallons)

Internal Pressure: 6 bar (87 psi)

4000 liter motor : 3/50/220/380 volt jacket 42 liter

Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,800 mm (70.9 in). Straight Side Length: 1,800 mm (70.9 in).

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Schwelm

Condition: Used

Material: Glasslined

Capacity (Design): 3,420 L (903.5 gallons)

Internal Pressure: 6 bar (87 psi)

3200 liter internal pressure 6 bar + vacuum @ 200 degrees C (3420 liter), jacket 6 bar @ 200 degrees C (320 liter), motor : 3/50/220/380

Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Diameter: 1,600 mm (63 in). Straight Side Length: 2,000 mm (78.7 in). Support Type: Legs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Schwelm

Condition: Used

Material: Glasslined

Capacity (Design): 950 L (251 gallons)

Internal Pressure: 10 bar (145 psi)

Shell and heads 12mm thick. Equipped w/800mm dia W/SEW variable speed drive Type RF73WRKeD100L-4, w/2.7 PS 3/50/220/480 volt, Type eG4 XP motor

Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,000 mm (39.4 in). Straight Side Length: 960 mm (37.8 in). Support Type: Legs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Schwelm

Condition: Used

Material: Glasslined

Capacity (Design): 5,300 L (1,400 gallons)

Internal Pressure: 2 bar (29 psi)

Blt to Swiss TUV standards.

Internal Full Vacuum: Yes. Jacket Pressure: 5 bar (72.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,800 mm (70.9 in).
