Carbon Steel Southern Heat Exchanger BEM Shell and Tube Heat Exchanger - IPP# 201670

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Western Supply

Model: BEM

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 299 m² (3,220 ft²)

Orientation: Horizontal

Pitch: 1.25" Triangular

Shell Pressure: 5.17 bar (75 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 5.17 bar (75 psi). Tube Temperature: 260 °C (500 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 914 mm (36 in). Head Material: Carbon Steel. Length: 7,264 mm (286 in). Shell-side Passes: 1. Tube-side Passes: 2. Tube Type: Straight Tube. Tube Number: 625. Tube Diameter: 3,429 mm (135 in). Tube Length: 6,096 mm (240 in). Capacity: 56,781 L (15,000 gallons).

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Southern Heat Exchanger

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 126 m² (1,360 ft²)

Orientation: Horizontal

With tubes: 24' around bend.

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204 °C (400 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Shell Diameter: 686 mm (27 in). Head Material: Carbon Steel. Shell-side Passes: 1. Tube-side Passes: 4. Tube Type: U-Tube. Tube Number: 276. Tube Diameter: 19.1 mm (0.75 in). Nozzle Schedule: Openings: Tube side- 2-6", shell side- 2-6" .

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: CO. A.S.T

Model: BEM

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 254 m² (2,732 ft²)

Orientation: Vertical

(re-boiler)
carbon steel (Fe-510-2kw) shell, shell 12mm thick
expansion bellow, (1) 316L stainless steel coned head, 9mm thick,
(1) 316L stainless steel dished welded on head

Shell Pressure: 0.827 bar (12 psi). Shell Temperature: 149 °C (300 °F). Shell Material: Carbon Steel. Tube Pressure: 0.552 bar (8 psi). Tube Temperature: 104 °C (220 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Shell Diameter: 1,244 mm (49 in). Head Material: Stainless Steel 316. Length: 7,000 mm (276 in). Tube Number: 343. Tube Diameter: 48.3 mm (1.9 in). Tube Length: 4,878 mm (192 in). Tube Thickness: 3.6 mm (0.142 in). Nozzle Schedule: openings tube side: (1) head with 1-740mm, (1) head with 1-500mm, 1-300mm, shell: 1-150mm, 1-100mm, 1-32mm.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Southern Heat Exchanger

Condition: Used

Material: Stainless Steel 304

Heat Transfer Surface Area: 136 m² (1,462 ft²)

Orientation: Horizontal

TEMA Type 23-238 AES
Order number 80-100,
1" pitch. 304SS tube sheet 28 1/8" diameter x 1 1/8" thick.
Exchanger has (1) channel head, (1) head floating head with external cover.
23' over all length.

Shell Pressure: 9.65 bar (140 psi). Shell Temperature: 62.8 °C (145 °F). Shell Material: Stainless Steel 304. Tube Pressure: 6.89 bar (100 psi). Tube Temperature: 93.3 °C (200 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304. Shell Diameter: 610 mm (24 in). Head Material: Carbon Steel. Length: 5,867 mm (231 in). Tube-side Passes: 4. Tube Type: Straight Tube. Tube Number: 376. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 6,035 mm (238 in). Tube Thickness: 1.65 mm (0.065 in). Nozzle Schedule: Openings include: Channel Head, (2) 6"; Shell (2) 6"..
