Stainless Steel 304 Dryer-Rotary Vacuum - IPP# 203024

Type: Dryer-Rotary Vacuum

Manufacturer: Stokes

Model: 900-59-125

Condition: Used

Material: Stainless Steel 316

Capacity Design: 7 m3 (247.2 ft3)

Diameter: 1,200 mm (48 in)

jacketed rotary vacuum dryer 3/50/380 volt Cleveland 63-55:1 ratio 3.8 HP, 1750 rpm gearbox shaft cored for steam heating, no national board, rated 50 psi @ 300 degrees F (1-straight side and 1-each end) Rotary union joint, outboard bearings. Unit with dust collector. Openings: top (2) 3' x 18 1/2" hinged access covers with counter balanced mechanism, 2-12"; end 1-8"; bottom 1-10" with manual open/close mechanism; jacket 4-6", 4-2", 4-1", 4-3/4"; shaft 1-2", 1-1 1/2".

Length: 6,100 mm (240 in). Temperature: 148.9 °C (300 °F). Rated for Vacuum: Yes. Heat Transfer Surface Area: 23.3 m² (251 ft²). Shaft Cored and National Board Stamped: Yes. Orientation: Horizontal. Operational Mode: Batch. Agitation: Yes. Dust Collection: Yes. Jacket Material: Carbon Steel. Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F).

Type: Dryer-Rotary Vacuum

Manufacturer: Blaw Knox

Condition: Used

Material: Stainless Steel 304

Capacity Design: 3.5 m3 (125 ft3)

Capacity Working: 2.3 m3 (82 ft3)

4' diameter x 10' long chamber. as 24" cored shaft with paddles and removable scrapers. No drive available. Unit has chain guards for drive. Top openings one 12", one 10 ". Jacket openings are 2" NPT. 12" bottom discharge.

Diameter: 1,200 mm (48 in). Length: 3,050 mm (120 in). Height: 2,150 mm (84 in). Rated for Vacuum: Yes. Heat Transfer Surface Area: 11.7 m² (126 ft²). Agitation Seal Type: Packing. Jacket Material: Carbon Steel.

Type: Dryer-Rotary Vacuum

Manufacturer: VOMM Turbotechnologia

Model: ES 2400

Condition: Used

Material: Stainless Steel 304

Capacity Design: 10 m3 (353.1 ft3)

Capacity Working: 6.6 m3 (233.1 ft3)

304 stainless steel jacketed turbo dryer, water content of dry product @ 0.5% and a dry particle size of >420 microns capacity, gas fired, steam drum type, 304 stainless steel drum, carbon steel rotor with 304 stainless steel lining, 460 volt, 60Hz, 500 rpm turbine speed, operating pressure of drum is slightly below atmospheric @ 180/100 degrees C, jacket 10 bar g @ 175 degrees C, design pressure of jacket 12 bar g @ 220 degrees C, internal blades to keep product on the sidewall and to push product down the dryer, internal self cleaning is done via reverse rotation of the drum

(1) approx 90m3/hr 304 stainless steel blower/fan, manufactured by Chicago Blower, type MPC-2/18, 1.165 kg/m3 Density, 30 degrees C, 3480 rpm, driven by 15kW, 3/60/460 volt, motor

(1) Superheated air generator with gas burner, manufactured by Babcock Wanson, type Mixbloc 500, 500,000 kcal/h, 150-200 degrees C outlet temperature, 0-30 degrees Inlet temperature, 1150 Ncm/hr combustion air delivery, 3000/5000/6000 Ncm/hr min/nor/max primary air delivery, natural gas fired, 60Hz, 460 volt,

Diameter: 1,300 mm (51.2 in). Length: 6,050 mm (238.6 in). Temperature: 400 °C (752 °F). Rated for Vacuum: Yes. Heat Transfer Surface Area: 28.5 m² (306.8 ft²). Orientation: Horizontal. Jacket Material: Stainless Steel 304. Jacket Pressure: 12 bar (174 psi). Jacket Temperature: 220 °C (428 °F). Jacket Type: Standard.

Type: Dryer-Rotary Vacuum

Manufacturer: Buflovak/Blaw Knox

Condition: Used

Material: Stainless Steel 304

Capacity Design: 1.56 m3 (55 ft3)

Capacity Working: 1.13 m3 (40 ft3)

rotary vac dryer 32" dia x 10' long shell. Bolt flat heads 12" dia charge port, 12" center btm discharge Approx 10" dia SS hollowshaft. 69.4 ratio

Diameter: 813 mm (32 in). Length: 3,050 mm (120 in). Temperature: 148.9 °C (300 °F). Pressure: 3.8 bar (55 psi). Rated for Vacuum: Yes. Heat Transfer Surface Area: 7.8 m² (84 ft²). Shaft Cored and National Board Stamped: Yes. Orientation: Horizontal. Agitation: Yes. Jacket Material: Carbon Steel.
