Stainless Steel 316 ITT Standard SSCF-C4P Shell and Tube Heat Exchanger - IPP# 203631

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: ITT Standard

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 2.6 m² (28 ft²)

Orientation: Vertical

• PN (Part Number) #: 5-080-08-996-922

Shell Pressure: 20.7 bar (300 psi). Shell Temperature: 260 °C (500 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 148.9 °C (300 °F). Tube Material: Carbon Steel. Shell Diameter: 218.9 mm (8.6 in). Head Material: Carbon Steel. Length: 2,800 mm (111 in). Tube Type: U-Tube. Tube Number: 18. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,450 mm (96 in). Nozzle Schedule: Shell nozzles are 3", Tube side nozzles are 3". Three vents 3/4", 4 connections 1/2", one drain 1"..

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: ITT Standard

Model: BSM 12x120

Condition: Used

Material: Monel

Heat Transfer Surface Area: 22.1 m² (238 ft²)

Orientation: Vertical

Monel 400 Heads/ Monel Tubes No heads with unit, requires direct piping or (2 )bolted heads.

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 148.9 °C (300 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 148.9 °C (300 °F). Tube Material: Monel. Head Material: Monel. Length: 3,050 mm (120 in). Nozzle Schedule: - Openings: Tube Side - (2) 3".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Cust-O-Fab

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 556 m² (6,000 ft²)

Orientation: Horizontal

• 1248 straight "Lo FIN" finned tubes
• 0.75" diameter x 0.065" under fin x approx. 10' long
• Four 4" auxiliary connections
• Four 1" vents/drains
• Twelve 3/4" NPT connections.

Shell Pressure: 5.2 bar (75 psi). Shell Temperature: 232.2 °C (450 °F). Shell Material: Stainless Steel 316. Tube Pressure: 5.2 bar (75 psi). Tube Temperature: 93.3 °C (200 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Head Material: Carbon Steel. Length: 4,150 mm (163 in). Tube Number: 1,248. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,050 mm (120 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: - Nozzle schedule as follows: Shell inlet One 36", shell outlet one 4", channel inlet/outlet are two 6".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: American Standard

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 3.2 m² (34 ft²)

Orientation: Horizontal

• Shell length: 3'

Shell Pressure: 15.5 bar (225 psi). Shell Temperature: 65.6 °C (150 °F). Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 232.2 °C (450 °F). Shell Diameter: 152.4 mm (6 in). Length: 914 mm (36 in). Tube Number: 116. Tube Diameter: 9.4 mm (0.37 in). Tube Thickness: 0.51 mm (0.02 in).
