Name: Rotary Compressor
Brand: Ingersoll Rand
SKU: 210339

Overview

Type:

Compressor

Subtype:

Rotary

Manufacturer:

Ingersoll Rand

Model:

SSR-HPE250-2S

Condition:

Used

Material:

Carbon Steel

Other Specifications

Compressor Type:

Rotary

Discharge Pressure:

9.9 bar (143 psi)

Inlet Diameter:

50.8 mm (2 in)

Pressure:

9.7 bar (140 psi)

Controls:

Yes

Cooling Type:

water

Enclosure:

Yes

Outlet Discharge Diameter:

76.2 mm (3 in)

Electric

Capacity

Flow Rate:

1,966 m3/h (1,157 CFM)

Motor

Motor Power:

186.4 kW (250 HP)

Motor Voltage:

460

Motor Hertz:

Motor Cycles:

Additional Info:

Air compressor single stage screw compressor, with all accessories piped, wired and base plate mounted in a packaged design with sound proof housing. Equipped with IR "Intellisys" digital controls, for operation of the entire system and allowing for modification of 12 variables in the controller logic. 3 inch NPT air discharge line, 2" NPT cooling water inlet and outlet ports, 0.5" NPT condensate drain line. Total package amps 310

Rotary Compressor

Type: Compressor

Subtype: Rotary

Manufacturer: Ingersoll Rand

Model: SSR-HPE250-2S

Condition: Used

Material: Carbon Steel

Compressor Type: Rotary

Discharge Pressure: 9.9 bar (143 psi)

Two stage, oil flooded, rotary, air compressor Single stage screw compressor, with all accessories piped, wired and base plate mounted in a packaged design with sound proof housing. Equipped with IR "Intellisys" digital controls, for operation of the entire system and allowing for modification of 12 variables in the controller logic. 3 inch NPT air discharge line, 2" NPT cooling water inlet and outlet ports, 0.5" NPT condensate drain line. Total package amps 310

Flow Rate: 1,966 m3/h (1,157 CFM). Inlet Diameter: 50.8 mm (2 in).
