Stainless Steel 304 Worsham Shell and Tube Heat Exchanger - IPP# 214337

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Western Supply

Model: AEL

Condition: Used

Material: Stainless Steel 304

Heat Transfer Surface Area: 123.5 m² (1,329 ft²)

Orientation: Vertical

4,170,000 BTU/Hr.

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 92.8 °C (199 °F). Shell Material: Stainless Steel 304. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 92.8 °C (199 °F). Tube Material: Stainless Steel 304. Shell Diameter: 635 mm (25 in). Head Material: Carbon Steel. Length: 6,096 mm (240 in). Tube-side Passes: 4. Tube Number: 254. Tube Diameter: 25.4 mm (1 in). Tube Length: 6,096 mm (240 in). Tube Thickness: 1.52 mm (0.06 in).

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Worsham Enterprises

Model: AETR

Condition: Unused

Material: Carbon Steel

Heat Transfer Surface Area: 975.5 m² (10,500 ft²)

Orientation: Horizontal

Size 59-240 (5) baffles in the shell on 2'4.5" spacing (1) channel head 3'7" long with flat bolted cover and one bolted dished head 2'1" OAL

Shell Pressure: 12.8 bar (185 psi). Shell Temperature: 110 °C (230 °F). Shell Material: Carbon Steel. Tube Pressure: 5.2 bar (75 psi). Tube Temperature: 65.6 °C (150 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Shell Diameter: 1,245 mm (49 in). Head Material: Carbon Steel. Length: 8,026 mm (316 in). Tube-side Passes: 2. Tube Number: 2,819. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 6,096 mm (240 in). Tube Thickness: 21.6 mm (0.85 in). Nozzle Schedule: - Openings: Shell - (1) 18", x(1) 20"; Heads (2) 16".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Worsham Enterprises

Model: AETR

Condition: Unused

Material: Carbon Steel

Heat Transfer Surface Area: 975.5 m² (10,500 ft²)

Orientation: Horizontal

Size 59-240

• Baffles: (5) in the shell on 2'4.5" spacing
• Head dimensions: (1) channel head 3'7" long with flat bolted cover and one bolted dished head 2'1" OAL

Shell Pressure: 12.8 bar (185 psi). Shell Temperature: 110 °C (230 °F). Shell Material: Carbon Steel. Tube Pressure: 5.2 bar (75 psi). Tube Temperature: 65.6 °C (150 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Shell Diameter: 1,245 mm (49 in). Head Material: Carbon Steel. Length: 8,026 mm (316 in). Tube-side Passes: 2. Tube Number: 2,819. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 6,096 mm (240 in). Tube Thickness: 2 mm (0.08 in). Nozzle Schedule: - Openings: Shell - (1) 18", x(1) 20"; Heads (2) 16".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Cosmos Minerals

Model: AEL

Condition: Used

Material: Hastelloy - B

Clad: Yes

Heat Transfer Surface Area: 30.8 m² (331 ft²)

Orientation: Horizontal

15.25" diameter x 1.5" thick. (2) Hastelloy B heads. Alloy 600 expansion joint n the shell.

Shell Pressure: 18.6 bar (270 psi). Shell Temperature: 232.2 °C (450 °F). Shell Material: Carbon Steel. Tube Pressure: 18.6 bar (270 psi). Tube Temperature: 232.2 °C (450 °F). Tube Material: Hastelloy - B. Tubesheet Material: Hastelloy - B. Vacuum: Yes. Shell Diameter: 406.4 mm (16 in). Head Material: Hastelloy - B. Length: 6,020 mm (237 in). Tube Number: 64. Tube Diameter: 25.4 mm (1 in). Tube Length: 6,020 mm (237 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: Openings include Tube side: (2) 6"; shell side (1) 4"; (1) 2". .
