design pressure tube side 7 bar @ -15/+235 deg C, shell side -1/5.3 bar @ -15/+135 deg C, (2) c/steel dished head
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Manufacturing Co.
Model: A-X-U-660-2743
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 22.5 m² (242.2 ft²)
Orientation: Horizontal
(1) c/steel flat channel head
Shell Pressure: 1.1 bar (16 psi). Shell Temperature: 210 °C (410 °F). Shell Material: Stainless Steel 316. Tube Pressure: 8.7 bar (126.2 psi). Tube Temperature: 180 °C (356 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 660 mm (26 in). Head Material: Carbon Steel. Length: 3,550 mm (140 in). Shell-side Passes: 1. Tube-side Passes: 6. Tube Type: U-Tube. Tube Number: 140. Tube Diameter: 19.5 mm (0.77 in). Tube Length: 2,950 mm (117.1 in). Nozzle Schedule: - Openings: tubeside - 2-2", shellside - 1-18", 1-6", 1-3".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Manufacturing Co.
Model: AXU-644-3698
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 42.8 m² (460.7 ft²)
Orientation: Horizontal
Expansion bellow (1) 316L s/steel channel head
Shell Pressure: 7 bar (101.5 psi). Shell Temperature: 200 °C (392 °F). Shell Material: Carbon Steel. Tube Pressure: 12.8 bar (185.6 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 927 mm (36.5 in). Head Material: Stainless Steel 316. Length: 4,600 mm (182.1 in). Shell-side Passes: 1. Tube-side Passes: 8. Tube Type: U-Tube. Tube Number: 196. Tube Diameter: 19.3 mm (0.76 in). Tube Length: 3,650 mm (144 in). Nozzle Schedule: - Openings: - Tubeside: 2-2" - Shell side: 2-6", 2-2".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Graham Manufacturing Co.
Model: AXU-644-3698
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 42.8 m² (460.7 ft²)
Orientation: Horizontal
(1) 316L s/steel channel head
Shell Pressure: 7 bar (101.5 psi). Shell Temperature: 200 °C (392 °F). Shell Material: Stainless Steel 316. Tube Pressure: 12.8 bar (185.6 psi). Tube Temperature: 200 °C (392 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 927 mm (36.5 in). Head Material: Stainless Steel 316. Length: 4,600 mm (182.1 in). Shell-side Passes: 1. Tube-side Passes: 8. Tube Type: U-Tube. Tube Number: 196. Tube Diameter: 19.3 mm (0.76 in). Tube Length: 3,650 mm (144 in). Nozzle Schedule: - Openings: - Tubeside: 2-2" - Shell side: 2-6", 2-2".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Manning and Lewis
Condition: Used
Material: Stainless Steel 304
Heat Transfer Surface Area: 100.8 m² (1,100 ft²)
Orientation: Horizontal
Job #: 161730
Shell Temperature: 176.7 °C (350 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 176.7 °C (350 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304. Head Material: Stainless Steel 304. Length: 4,850 mm (191 in). Tube Type: Straight Tube. Tube Number: 402. Tube Diameter: 19.1 mm (0.75 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: - Shell side nozzles: two 4" with 1" vents and drains - Tube side nozzles: 2" and 1.5" with 1/2 " vent and drains.. Capacity: 568 L (150 gallons).
