Unused Carbon Steel Shell and Tube Heat Exchanger - IPP# 228360

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 13.9 m² (150 ft²)

Orientation: Vertical

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Alloy 20. Tubesheet Material: Alloy 20. Vacuum: Yes. Shell Diameter: 609.6 mm (24 in). Head Material: Nickel. Length: 558.8 mm (22 in). Shell-side Passes: 4. Tube-side Passes: 4. Tube Type: Straight Tube. Tube Number: 481. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 558.8 mm (22 in). Tube Thickness: 457.2 mm (18 in). Nozzle Schedule: (2) 4" inlet/outlet, (2) 1" vent/drain, (1) 1/2" drain, (1) 10" inlet. (1) 3" outlet. (1) 4" outlet.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Condition: Used

Material: Carbon Steel

Heat Transfer Surface Area: 18.6 m² (200 ft²)

Orientation: Vertical

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Nickel. Tubesheet Material: Alloy 20. Vacuum: Yes. Shell Diameter: 508 mm (20 in). Length: 1,473 mm (58 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 1.91 mm (0.08 in). Tube Length: 1,473 mm (58 in). Tube Thickness: 457.2 mm (18 in). Nozzle Schedule: (1x) 10" inlet, (1x) 3" outlet, (1x) 4" outlet, (2x) 4" inlet/outlet (2x) 1" vent/drain.

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Model: BEM 20-60

Condition: Used

Material: Hastelloy - Other

Clad: Yes

Heat Transfer Surface Area: 27.9 m² (300 ft²)

Orientation: Vertical

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Hastelloy - Other. Tubesheet Material: Hastelloy - C276. Vacuum: Yes. Shell Diameter: 508 mm (20 in). Head Material: Hastelloy - Other. Length: 1,448 mm (57 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,448 mm (57 in). Tube Thickness: 1.24 mm (0.05 in). Nozzle Schedule: One 10", Three 4", One 3", Two 1".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Atlas Industrial

Model: TEMA BEM 17-96

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 37.2 m² (400 ft²)

Orientation: Vertical

Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204.4 °C (400 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 457.2 mm (18 in). Head Material: Stainless Steel 316L. Length: 3,353 mm (132 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 262. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 2,388 mm (94 in). Tube Thickness: 1.24 mm (0.05 in). Nozzle Schedule: One 12", Three 3", Two 2", and Two 1".
