Glasslined Tycon CE Batch-Type Agitated Reactor - IPP# 231072

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Tycon

Model: CE

Condition: Used

Material: Glasslined

Capacity (Design): 9,350 L (2,470 gallons)

Internal Pressure: 6 bar (87 psi)

Rated -1/6 bar @ -60 to 200 degrees C internal;
-1/6 bar @ -60 to 200 degrees C in the jacket.
jacket 750 liters

• Type: CE8000
• Mounting: mounted on mounting ring.
• Heat transfer area: 17.9 Sqm

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 2,200 mm (86.6 in). Straight Side Length: 3,426 mm (135 in).

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: Pfaudler

Model: CE

Condition: Used

Material: Glasslined

Capacity (Design): 2,115 L (559 gallons)

Internal Pressure: 6 bar (87 psi)

Order number: 68525
internal pressure -1/6 bar @ 200 degrees C (total volume 2115 liter)
jacket pressure 7 bar @ 200 degrees C (volume 319 liter)
with 10hp/600rpm/VS-10 Pfaudler gear, ratio 1:5,05,
belt driven by a 3,6kW/3~/50Hz/380-660V/1430rpm/Ex proof motor.

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 7 bar (102 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Diameter: 1,500 mm (59.1 in). Straight Side Length: 1,200 mm (47.2 in). Support Type: Lugs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: DeDietrich

Model: CE

Condition: Used

Material: Glasslined

Capacity (Design): 11,700 L (3,091 gallons)

Internal Pressure: 6 bar (87 psi)

internal pressure -1/6 bar @ -10/+200 degrees C
jacket 7 bar @ -10+200 degrees C
jacket 1100 ltr.
400mm diameter x 3180mm tangent to tangent,
VonRoll drive, 40/80 rpm,
belt driven by a BBC 13/20kW, 3/50 /380V, 700/1400rpm motor,
with mechanical seal on shaft with lubricator pump.
Total weight 12,000 kg

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 7 bar (102 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 2,400 mm (94.5 in). Straight Side Length: 3,180 mm (125 in). Support Type: Lugs.

Type: Reactor

Subtype: Batch-Type Agitated

Manufacturer: DeDietrich

Model: CE

Condition: Used

Material: Glasslined

Capacity (Design): 14,335 L (3,787 gallons)

Internal Pressure: 4 bar (58 psi)

Code number: 400930
(2) flat baffles,
agitator drive MDL125-140 with 30kW 3/50hz/220/380V/1460rpm E-motor.
belt driven.
bottom glass lined valve available,
built to CODAP 85,

Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 180 °C (356 °F). Orientation: Vertical. Agitation: Yes. Diameter: 2,400 mm (94.5 in). Straight Side Length: 2,545 mm (100 in).
