Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 189.3 L (50 gallons)
Internal Pressure: 5.5 bar (80 psi)
With 2.5DTW drive, belt driven by a 3 HP, 3/60/230/460 volt motor,
Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 148.9 °C (300 °F). Orientation: Vertical. Agitation: Yes. Diameter: 609.6 mm (24 in). Straight Side Length: 711.2 mm (28 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 9,464 L (2,500 gallons)
Agitation: Yes
driven by 10 HP, 3/60/460V,
Diameter: 2,134 mm (84 in). Straight Side Length: 2,438 mm (96 in). Support Type: Legs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 2,839 L (750 gallons)
Internal Pressure: 5.2 bar (75 psi)
jacket on straight side and bottom head. 5 HP, 220/440 volt, 1725 rpm motor, UL label.
Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 12.4 bar (180 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Stainless Steel Other. Orientation: Vertical. Agitation: Yes. Diameter: 1,524 mm (60 in). Straight Side Length: 1,676 mm (66 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 1,893 L (500 gallons)
Internal Pressure: 3.8 bar (55 psi)
No mixer but has drive bosses on top head
Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 2.8 bar (40 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Diameter: 1,524 mm (60 in). Straight Side Length: 1,016 mm (40 in). Support Type: Legs.
