Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Doyle and Roth
Condition: Used
Material: Stainless Steel 304
Heat Transfer Surface Area: 68.1 m² (733 ft²)
Orientation: Horizontal
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 121.1 °C (250 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 121.1 °C (250 °F). Tube Material: Stainless Steel 304. Tubesheet Material: Stainless Steel 304. Head Material: Carbon Steel. Tube Type: U-Tube. Tube Number: 282. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,962 mm (156 in). Tube Thickness: 0.06 mm (0.002 in). Nozzle Schedule: Nozzle schedule is : Three 6", one 12", and two 3/4" vent/drain(s)..
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Doyle and Roth
Condition: Used
Material: Stainless Steel Austenitic
Heat Transfer Surface Area: 10 m² (108 ft²)
Orientation: Horizontal
vapor condenser(shell and tube) with surge head cylinder. Surge cylinder is 6" diameter x 5' long.
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 86.2 bar (1,250 psi). Tube Temperature: 315.6 °C (600 °F). Tube Material: Stainless Steel Austenitic. Tubesheet Material: Carbon Steel. Length: 3,734 mm (147 in). Tube Type: Straight Tube. Tube Number: 45. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,734 mm (147 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: One 8" nozzle, six 2" nozzles..
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Doyle and Roth
Condition: Used
Material: Stainless Steel Austenitic
Heat Transfer Surface Area: 10 m² (108 ft²)
Orientation: Horizontal
vapor condenser(shell and tube) with surge head cylinder, Surge cylinder is 6" diameter x 5' long.
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204.4 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 86.2 bar (1,250 psi). Tube Temperature: 315.6 °C (600 °F). Tube Material: Stainless Steel Austenitic. Tubesheet Material: Carbon Steel. Length: 3,734 mm (147 in). Tube Type: Straight Tube. Tube Number: 45. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,734 mm (147 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: One 8" nozzle, six 2" nozzles..
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Doyle and Roth
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 30.1 m² (324 ft²)
Orientation: Horizontal
Shell Pressure: 12.4 bar (180 psi). Shell Temperature: 193.3 °C (380 °F). Shell Material: Carbon Steel. Tube Pressure: 12.4 bar (180 psi). Tube Temperature: 193.3 °C (380 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Head Material: Stainless Steel 316. Length: 4,873 mm (191.9 in). Tube Type: Straight Tube. Tube Number: 104. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 4,851 mm (191 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: Four 3" nozzles..
