Unused Stainless Steel 316L Alfa Laval CPX75-V-500 Pls Welded Plate Heat Exchanger - IPP# 246638

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CPX50-V-150 Pls

Condition: Unused

Material: Stainless Steel 316L

Heat Transfer Surface Area: 41.9 m² (451 ft²)

Process Pressure: 16 bar (232.1 psi)

41.9m² 1.4547 stainless steel plate and carbon steel frame Compabloc heat exchanger, CE confirm, manufactured by Alfa Laval, serial number CP50-2776, Side A pressure rated by -1/16bar @ -40/180 degrees C (volume 151.2 liter), Side B pressure rated by -1/16bar @ -40/180 degrees C (volume 165.5 liter) (150) 1.4547 stainless steel plates, openings: Hot side (2)DN25, (2)DN100; Cold side (2)DN25, (2)DN200. as per drawing * new plate pack in SMO * new baffle system in SMO * new gaskets * design temp. increase from 150 to 180 degrees C

Process Temperature: 180 °C (356 °F).

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CPL20-H-60

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 3.8 m² (40.7 ft²)

Process Pressure: 10 bar (145 psi)

• Compabloc welded plate heat exchanger,
• design pressure process side: 10 barg + full vacuum @ -25/165 degrees C (17.3 liter),
• service side: 10 barg + full vacuum @ -29/185 degrees C (16.9 liter),
• 2-pass process side, 6-pass service side,
• (60) 316L (1.4404) stainless steel welded plates,
• openings process side 3-50mm, service side: 2-50mm,
• design code: ADM (PED CAT 3)

Process Temperature: 165 °C (329 °F).

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CPL30-H-80

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 9 m² (96.9 ft²)

Process Pressure: 10 bar (145 psi)

• Compabloc welded plate heat exchanger,
• design pressure process side: 10 barg + full vacuum @ -25/165 degrees C (34.4 liter),
• service side: 10 barg + full vacuum @ -29/185 degrees C (33.5 liter),
• 1-pass process side, 6-pass service side,
• (80) 316L (1.4404) stainless steel welded plates,
• openings process side 1-100mm, 1-50mm, service side: 2-50mm,
• design code: ADM (PED CAT 3)

Process Temperature: 165 °C (329 °F).

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CP30-C-160PLs

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 17.3 m² (186.2 ft²)

Process Pressure: 6 bar (87 psi)

• Compabloc welded plate heat exchanger,
• design pressure: process side: 6 barg + full vacuum @ 0/185 degrees C (82 liter)
• design pressure: service side: 8 barg + full vacuum @ 0/185 degrees C (67 liter)
• 1+1-pass process side,
• 4-pass service side
• (160) 316L stainless steel welded plates
• openings process side: 1-250mm, 1-100mm, 1-50mm, service side: 2-100mm
• mounted on lugs
• design code: AD-Merkblatt Ed.2000

Process Temperature: 185 °C (365 °F).
