Dryer Rated FV &10.35 bar (150PSI) @ -29 to 177 degrees C ( -20/+350 deg F) internal , jacket rated 10.35 bar (150 PSI) @ -29 to 177 degrees C (-20/+350 deg F) Unit is 18" ID, 24" OD x 34" straight side Interior fininsh is polished to 180 grit finish Shaft is cored for heating/ cooling, packing gland on shaft Filter volume 170 liter, shaft volume 5 liter, jacket volume 18 liters Clamp bottom has (3) legs with wheels for removing bottom head to access filter plate Included hydraulic power drive mounted in a SS stand for filter, drive, and controls.
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: Cogiem
Model: FFP-030-DFM
Condition: Used
Material: Hastelloy - C276
Filtration Area: 0.3 m² (3.2 ft²)
Pressure: 6 bar (87 psi)
Filter interior is polished to a mirror polish (220 grit)With cored and heated shaftshaft rated for 87 psi at 208 degrees F.Hydraulic driven agitator rotation 1:14 from 6-58 rpm.With stuffing box agitator seal with gas purge. Hydraulic power pack operates the following.Agitator up/down, Bottom openingtiltingand the hatchPower pack is driven by a Reliance 10 hp 460volt, 3 ph motorSide solids dischargelamped bottom for heads removalTilting type filterWith 316 SS base and cabinetexterior parts polished to an 80 grit finishAll gaskets are PTFE.Filter has washing nozzles, and Explosion proof lighting for filter interiorAlso included is a Rosenmund Apovac Vacuum systemincluding vacuum pump and ring -Liquid vessel and coolerApovac model 1.5/660 PMSH 156 D2Serial # 51 050with Vacuum pump by Gepruft With PLC control systemhas operators controls mounted on hydraulic station
Temperature: 165 °C (329 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 165 °C (329 °F).
Type: Filter
Subtype: Rosenmund and Cogiem
Manufacturer: 3V Cogeim
Model: Filtrodry FPP 100 SD/FM
Condition: Used
Material: Hastelloy - C276
Filtration Area: 1 m² (10.8 ft²)
Diameter: 1,200 mm (47.2 in)
Pressure: 6.9 bar (100.1 psi). Temperature: 177 °C (350.6 °F). Vacuum: Yes. Internal Finish: Ra 0.5. Agitation Seal Type: Mechanical. Jacket: Yes. Jacket Pressure: 10.4 bar (150.1 psi). Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 316. Jacket Temperature: 177 °C (350.6 °F). Agitator Cored for Heating/Cooling: Yes. Vessel Liquid Capacity: 1,500 L (400 gallons).
