Used
Carbon Steel
Obringer/Sotralentz
25.3 m² (272.3 ft²)
Horizontal
53 bar (768.7 psi)
95 °C (203 °F)
Copper/Brass
7.5 bar (108.8 psi)
50 °C (122 °F)
Carbon Steel
Carbon Steel
610 mm (24 in)
Carbon Steel
3,515 mm (138.4 in)
4
U-Tube
186
19.1 mm (0.75 in)
2,268 mm (89.3 in)
2.1 mm (0.08 in)
openings tube side: bonnet head with 2-100mm, shell: 2-100mm, 2-50mm,

working pressure tube side 7.5 barg (0.75 Mpa) @ 50 degrees C (350 liter ), shell side 53 barg (5.3 Mpa) @ 95 degrees C (450 liter) (1) carbon steel bonnet head, (1) carbon steel tubesheet, design code: CODAP 95 A f2,
