(1) c/steel channel head
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: SRI
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 28.8 m² (310 ft²)
Orientation: Horizontal
Expansion bellow (2) 316 s/steel bonnet heads,
Shell Pressure: 10 bar (145 psi). Shell Temperature: 350 °C (662 °F). Shell Material: Carbon Steel. Tube Pressure: 13.5 bar (195.8 psi). Tube Temperature: 350 °C (662 °F). Tube Material: Stainless Steel 316. Tubesheet Material: Stainless Steel 316. Vacuum: Yes. Shell Diameter: 355 mm (14 in). Head Material: Stainless Steel 316. Length: 5,500 mm (216.5 in). Shell-side Passes: 1. Tube-side Passes: 8. Tube Number: 100. Tube Diameter: 20 mm (0.79 in). Tube Length: 4,900 mm (192 in). Nozzle Schedule: - Openings: - Tubeside: (1) head with 2-2", (1) head with none - Shell side: 3-2".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: SRI
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 33.2 m² (357.4 ft²)
Orientation: Horizontal
Shell Pressure: 20 bar (290.1 psi). Shell Temperature: 220 °C (428 °F). Shell Material: Carbon Steel. Tube Pressure: 13.5 bar (195.8 psi). Tube Temperature: 220 °C (428 °F). Tube Material: Stainless Steel Other. Tubesheet Material: Stainless Steel Other. Vacuum: Yes. Shell Diameter: 400 mm (15.7 in). Head Material: Stainless Steel Other. Tube Number: 144. Tube Diameter: 19 mm (0.75 in). Tube Length: 3,650 mm (144.5 in). Nozzle Schedule: - Tube side openings: - 1 head with 2-3" - 1 head with none - Shell side openings: - 1-3" - 2-2" .
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: SRI
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 38 m² (409 ft²)
Orientation: Horizontal
(1) c/steel bonnet head
Shell Pressure: 5.3 bar (76.9 psi). Shell Temperature: 180 °C (356 °F). Shell Material: Stainless Steel Other. Tube Pressure: 8.7 bar (126.2 psi). Tube Temperature: 180 °C (356 °F). Tube Material: Stainless Steel Other. Vacuum: Yes. Shell Diameter: 473 mm (18.6 in). Head Material: Carbon Steel. Length: 4,200 mm (165.4 in). Shell-side Passes: 1. Tube-side Passes: 2. Tube Type: U-Tube. Tube Number: 110. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,850 mm (152 in). Tube Thickness: 1.65 mm (0.06 in). Nozzle Schedule: - Openings: - Tubeside: 2-6" - Shell side: 1-4", 1-3".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: SRI
Model: 25-BEM-36
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 38 m² (409 ft²)
Orientation: Horizontal
duplex tubesheet Expansion bellows material: 316 s/steel (1.4571) (1) Duplex (1.4462) bonnet head (1) Duplex (1.4462) coned head
Shell Pressure: 8.7 bar (126.2 psi). Shell Temperature: 180 °C (356 °F). Shell Material: Carbon Steel. Tube Pressure: 7 bar (101.5 psi). Tube Temperature: 180 °C (356 °F). Tube Material: Stainless Steel Other. Vacuum: Yes. Shell Diameter: 406 mm (16 in). Head Material: Stainless Steel Other. Length: 4,500 mm (176.7 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Number: 177. Tube Diameter: 19 mm (0.75 in). Tube Length: 3,650 mm (144 in). Tube Thickness: 1.5 mm (0.06 in). Nozzle Schedule: - Tubeside openings: Coned head with 1-10", 2-2", bonnet head with 1-4", 1-2" - Shell side openings: 2-4", 1-2".
