Stainless Steel Other Graham heat process ltd AEL-762-4878 Shell and Tube Heat Exchanger - IPP# 221548

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Graham heat process LTD.

Model: AEL-26-192

Condition: Used

Material: Stainless Steel 321

Heat Transfer Surface Area: 99.2 m² (1,050 ft²)

Orientation: Vertical

(2) c/steel flat channel heads

Shell Pressure: 5.3 bar (76.9 psi). Shell Temperature: 150 °C (302 °F). Shell Material: Stainless Steel 321. Tube Pressure: 10.5 bar (152.3 psi). Tube Temperature: 150 °C (302 °F). Tube Material: Stainless Steel 321. Tubesheet Material: Stainless Steel 321. Vacuum: Yes. Shell Diameter: 660 mm (26 in). Head Material: Carbon Steel. Length: 5,700 mm (225.4 in). Shell-side Passes: 1. Tube-side Passes: 4. Nozzle Schedule: - Head openings: Tubeside - (1) head with 2-6", (1) head with 2-1"; Shell side - 1-8", 1-3", 1-2".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Hughes & Anderson

Condition: Used

Material: Stainless Steel Other

Heat Transfer Surface Area: 195.6 m² (2,100 ft²)

Orientation: Horizontal

Shell Pressure: 1.03 bar (15 psi). Shell Temperature: 148.9 °C (300 °F). Shell Material: Stainless Steel Other. Tube Pressure: 6.9 bar (100 psi). Tube Temperature: 93.3 °C (200 °F). Tube Material: Stainless Steel Other. Head Material: Carbon Steel. Length: 3,950 mm (156 in). Shell-side Passes: 1. Tube-side Passes: 10. Tube Number: 1,100. Tube Diameter: 19.1 mm (0.75 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: - Tube nozzles: Two 6" - Shell nozzles: One 16" and one 20".

Type: Heat Exchanger

Subtype: Shell and Tube

Condition: Used

Material: Stainless Steel Other

Heat Transfer Surface Area: 9.3 m² (100 ft²)

Orientation: Horizontal

(2) bolted dished heads.

Shell Material: Carbon Steel. Tube Material: Stainless Steel Other. Head Material: Stainless Steel Other. Length: 1,500 mm (60 in). Nozzle Schedule: Openings include: Heads (1) 4", (1) 2"; Shell (2) 3"..

Type: Heat Exchanger

Subtype: Shell and Tube

Condition: Used

Material: Stainless Steel Other

Heat Transfer Surface Area: 9.5 m² (102 ft²)

Orientation: Vertical

expansion joint in shell
