Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Hughes & Anderson
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 195.6 m² (2,100 ft²)
Orientation: Horizontal
Shell Pressure: 1.03 bar (15 psi). Shell Temperature: 148.9 °C (300 °F). Shell Material: Stainless Steel Other. Tube Pressure: 6.9 bar (100 psi). Tube Temperature: 93.3 °C (200 °F). Tube Material: Stainless Steel Other. Head Material: Carbon Steel. Length: 3,950 mm (156 in). Shell-side Passes: 1. Tube-side Passes: 10. Tube Number: 1,100. Tube Diameter: 19.1 mm (0.75 in). Tube Thickness: 1.52 mm (0.06 in). Nozzle Schedule: - Tube nozzles: Two 6" - Shell nozzles: One 16" and one 20".
Type: Heat Exchanger
Subtype: Shell and Tube
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 9.3 m² (100 ft²)
Orientation: Horizontal
(2) bolted dished heads.
Shell Material: Carbon Steel. Tube Material: Stainless Steel Other. Head Material: Stainless Steel Other. Length: 1,500 mm (60 in). Nozzle Schedule: Openings include: Heads (1) 4", (1) 2"; Shell (2) 3"..
Type: Heat Exchanger
Subtype: Shell and Tube
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 9.5 m² (102 ft²)
Orientation: Vertical
expansion joint in shell
Shell Material: Carbon Steel. Tube Material: Stainless Steel Other. Head Material: Stainless Steel Other. Tube Diameter: 304.8 mm (12 in). Tube Length: 2,450 mm (96 in). Nozzle Schedule: Openings: One Head (1) 6", (1) 8"; Other Head (1) 2"..
Type: Heat Exchanger
Subtype: Shell and Tube
Condition: Used
Material: Stainless Steel Other
Heat Transfer Surface Area: 1.1 m² (11.8 ft²)
Orientation: Horizontal
Shell Material: Carbon Steel. Tube Material: Stainless Steel Other. Head Material: Stainless Steel Other. Nozzle Schedule: - Openings: - Shell side: (2) DN 50 and (1) DN 25 - Tube side: (2) DN 25.
