Stainless Steel 316L Titanium Fabricators Ltd Shell and Tube Heat Exchanger - IPP# 242505

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Titanium Fabricators Ltd

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 20.8 m² (223.9 ft²)

Orientation: Vertical

• design pressure tube side 3.5 bar + full vacuum @ 180 degrees C
• shell 8 bar @ 80 degrees C
• shell with expansion bellows
• (1) 316L stainless steel bolt channel head with removeable flat end plate
• (1) 316L stainless steel bolt coned head
• design code: BS5500 CAT 2 (1991) & TEMA 'B' 1988

Shell Pressure: 8 bar (116 psi). Shell Temperature: 80 °C (176 °F). Shell Material: Stainless Steel 316L. Tube Pressure: 3.5 bar (50.8 psi). Tube Temperature: 180 °C (356 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 324 mm (12.8 in). Head Material: Stainless Steel 316L. Length: 4,600 mm (180.5 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 99. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,550 mm (140.6 in). Tube Thickness: 1.65 mm (0.07 in). Nozzle Schedule: top head with 1-150mm, bottom head with 1-150mm, shell 2-80mm, 1-3/4".

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Titanium Fabricators Ltd

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 3.8 m² (40.8 ft²)

Orientation: Vertical

• pressure side A: 4 barg + full vacuum @ -29/185 degrees C
• side B: 10 barg + full vacuum @ -29/185 degrees C,
• 1-316L stainless steel channel head with removeable flat end plate
• 1-316L stainless steel reduction coned head
• shell with expansion bellows
• design code: BS5500 CAT 2 (1991) & TEMA 'B' 1988

Shell Pressure: 10 bar (145 psi). Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Tube Pressure: 4 bar (58 psi). Tube Temperature: 185 °C (365 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 273 mm (10.7 in). Head Material: Stainless Steel 316L. Length: 2,100 mm (82.3 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 38. Tube Diameter: 25.7 mm (1.01 in). Tube Length: 1,300 mm (50.7 in). Nozzle Schedule: tube side: top head with 1-80mm, bottom head with 1-150mm, shell: 2-80mm, .

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: Titanium Fabricators Ltd

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 2.9 m² (31.2 ft²)

Orientation: Vertical

• design pressure tube side -1/4 barg @ -29/185 degrees C,
• shell side -1/10 barg @ -29/185 degrees C,
• (1) channel head with removable flat end plate
• 1-reduction cone head,
• shell with expansion bellows
• design code: BS5500 1991 CAT 2 & TEMA 'B' 1988

Shell Pressure: 10 bar (145 psi). Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Tube Pressure: 4 bar (58 psi). Tube Temperature: 185 °C (365 °F). Tube Material: Stainless Steel 316L. Tubesheet Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 273 mm (10.7 in). Head Material: Stainless Steel 316L. Length: 2,100 mm (82.3 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 38. Tube Diameter: 25.4 mm (1 in). Tube Length: 1,300 mm (50.7 in). Tube Thickness: 1.65 mm (0.06 in). Nozzle Schedule: tube side: top head with 1-80mm, bottom head with 150mm, shell: 2-80mm, 1-3/4".
