Kohler 40REOZJB 40KW Diesel Electric Power Generator - IPP# 247022

Type: Power Generator

Manufacturer: Kohler

Model: 150R0XJ71

Condition: Used

Material: Carbon Steel

Capacity: 0.15 MW

Amperage: 600 amp

150KW Diesel backup generator. manufactured by Kohler

Voltage: 240. Cycle: 60. Phase: 3. Emergency: Yes. Operational Hours: 8,293. Drive Power: 150 kW (201.2 HP). Fuel Type: Diesel. Power Transmission: Direct Coupled. Batteries: Yes. Battery Charger: Yes. Controls: Yes.

Type: Power Generator

Manufacturer: Kato

Model: A261820000

Condition: Used

Material: Carbon Steel

Capacity: 0.28 MW

Amperage: 428.5 amp

Skid mounted turbine generator package This set is designed to recover the work available in high pressure steam that would normally be lost when the steam passes through a pressure reducing valve The system consists of a backpressure steam turbine driving a synchronous generator mounted on a skid The control system automatically controls the flow of the steam through the turbine, thereby controlling the pressure in the low pressure header. The major components are as follows: Turbine by Coppus Engineering, Model # RLHA-19, Serial # 94H9489. This is a single-stage, impulse type turbine. Capable of delivering 404 HP at 3600 rpm, designed for 23,075 lbs. /hr, of dry saturated steam at 210 psi.
Generator is manufactured by Kato, and is high efficiency design, synchronous, and brushless, and revolving field style ; Type: 26182 Operating at 3600 rpm, delivering 480 volt, 3 ph, 60 Hz, 283 kW of output. Alternator kW continuous, 285, 60 Hz, 277/480v, 428.5 amps. Exciter Arm "C" # 3007-10, Exciter Field "C" # 18058-10. The control panel and circuit breaker handle synchronization, metering, protection and other functions.

Voltage: 480. Cycle: 60. Phase: 3. Drive Power: 283 kW (379.5 HP). Powered By: Steam. Controls: Yes.

Type: Power Generator

Manufacturer: Elliott

Model: BYRH-UG

Condition: Used

Material: Carbon Steel

Capacity: 1.01 MW

Amperage: 163 amp

Elliott steam turbine generator set with Elliott turbines Single stage back pressure style units. We believe this unit has zero run hours since the overhaul. Engine, gearbox and generator are mounted in a common skid. Rated Power - 1350HP/1007kW; Rated Turbine Speed - 5750 RPM; Rated Inlet Steam Pressure - Gauge - 599 PSI; Rated Steam Temperature - 750 Deg F; Rated Exhaust Pressure - 155 PSI. Gear Drive is a model # C4 R4, Serial # B102145C-G2, Rated power 1350, Service factor 1.66, High speed shaft;5750, Low speed shaft;1815 , Tag # 802654 C4 2625. Alternater is built by BBC (Brown Boveri) Serial # C36-A076-101, Drive end bearing 6322/C3, opposite drive end bearing 6320/C3. Time rated continuous; Frame # 717, enclosure is drip proof; rated ambient temp. 40 degrees C. With twin Amtek oil coolers and 1.5 hp oil pump.

Voltage: 4,160. Cycle: 60. Phase: 3. Drive Power: 1,000 kW (1,350 HP). Power Transmission: Gear. Powered By: Steam. Controls: Yes.

Type: Power Generator

Manufacturer: Ideal

Condition: Used

Material: Carbon Steel

Capacity: 10.2 MW

Amperage: 1,600 amp

• Can be used with Terry condensing turbine IPP stock # 212616.
• Ideal Generator. The generator is an electric, four pole synchronous AC brushless generator.
• Horizontal design, two bearing style, with single shaft extension.
• Windings intended to be WYE with full six leads, brought out, and equipped with damper windings to facilitate parallel operation with other generators.
• Bearings are sleeve type and electrically insulated and forced oil is fed from an outside source. Bearings are also equipped with dial thermometers, return sight flow glass', and RTD protection. The bearings are also equipped with vibration probes in an X-Y orientation.
• Space heaters are also included and operate at 2400 watts, 120 vac, 60 hz.

Voltage: 4,160. Cycle: 60. Phase: 3. Power Transmission: Direct Coupled. Powered By: Steam.
