Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657

  • Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657 Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657
  • Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657 Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657
  • Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657
  • Glasslined Pfaudler-Balfour CE4000 Batch-Type Agitated Reactor - IPP# 242657
Overview
Reactor
Batch-Type Agitated
Pfaudler-Balfour
CE4000
Used
Glasslined
4,900 L (1,300 gallons)
Glass Lined
Pressure Vessel
6.6 bar (95.7 psi)
Yes
185 °C (365 °F)
Jacket/Internal Coil
10 bar (145 psi)
185 °C (365 °F)
Standard
Carbon Steel
Dimensions
Vertical
1,800 mm (70.9 in)
1,600 mm (62.2 in)
Agitation System
Yes
Retreat Curve
Mechanical with Gas
11 kW (14.8 HP)
11 kW (14.8 HP)
Beavertail
Heads
Dish
Glasslined
Dish
Glasslined
Other Specifications
Yes
Lugs
Inlets & Outlets
openings top: 1-500mm stainless steel manway cover with PTFE lining and davit assit (2-100mm sightglasses, 2-250mm, 4-100mm (1 with baffle), 1-100/50mm (dip pipe on grate cover), 1-25mm (jacket), side jacket: 2-80mm, 2-50mm, bottom: 1-150mm, 2-80mm (jacket)
Additional Information
  • 4000 liter working capacity,
  • design pressure internal -1/6.6 bar @ -29/185 degrees C,
  • jacket -1/10 bar @ -29/185 degrees C (570 liter),
  • glass type 9129 white glass,
  • shaft speed 10-90 rpm,
  • EExd IIB T4 IP55 motor,
  • white glass body, shaft and blue glass baffle
  • design code: ASME VIII DIV I 1989 with addenda up to and including winter 1990
