Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Stalwart International
Model: 6000
Condition: New
Material: Stainless Steel 316
Capacity (Design): 22,712 L (6,000 gallons)
Internal Pressure: 9 bar (130 psi)
Internal Full Vacuum: Yes. Internal Temperature: 232.8 °C (451 °F). Sanitary Construction: Yes. Jacket Pressure: 9 bar (130 psi). Jacket Temperature: 2,511 °C (4,551 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Diameter: 2,794 mm (110 in). Straight Side Length: 3,378 mm (133 in). Support Type: Legs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Stalwart International
Model: 6000
Condition: New
Material: Stainless Steel 316L
Capacity (Design): 22,712 L (6,000 gallons)
Internal Pressure: 10 bar (145 psi)
NEW/UNUSED 240 grit buff polished -Bright polished , external buff polish to matte finish.
Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Body Only: Yes. Orientation: Vertical. Agitation: Yes. Diameter: 2,794 mm (110 in). Straight Side Length: 3,480 mm (137 in). Support Type: Legs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Stalwart International
Condition: New
Material: Stainless Steel 316
Capacity (Design): 7,571 L (2,000 gallons)
Internal Pressure: 10 bar (145 psi)
UNUSED Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated and "U" stamped. welded dish heads (2:1) 10mm thick. Coil: 114 mm OD x 4 mm thick, Limpet covers bottom dish and 2028 mm of straight-side (pitch 150mm), Span 1000mm. Coil heating surface area. With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug 18" Manhole with Cover and davit arm assist, One 6" sight glass
Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Diameter: 2,000 mm (78.7 in). Straight Side Length: 2,400 mm (94.5 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Stalwart International
Condition: New
Material: Stainless Steel 316
Capacity (Design): 2,271 L (600 gallons)
Internal Pressure: 3.4 bar (50 psi)
Internal Full Vacuum: Yes. Internal Temperature: 250 °C (482 °F). Sanitary Construction: Yes. Jacket Pressure: 5.9 bar (85 psi). Jacket Temperature: 300 °C (572 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Diameter: 1,016 mm (40 in). Straight Side Length: 2,896 mm (114 in). Support Type: Legs.
