Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Model: RA 4000
Condition: Needs Reglass
Material: Glasslined
Capacity (Design): 15,150 L (4,000 gallons)
Internal Pressure: 6.9 bar (100 psi)
Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 5.9 bar (85 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Diameter: 2,450 mm (96 in). Straight Side Length: 2,750 mm (108 in). Support Type: Legs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Model: P
Condition: Re-glassed
Material: Glasslined
Capacity (Design): 37.9 L (10 gallons)
Internal Pressure: 1.72 bar (25 psi)
Reglassed at UGE facility 105 psi w/full vac int. Glass #59.
Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Diameter: 355.6 mm (14 in). Straight Side Length: 457.2 mm (18 in). Support Type: Legs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Model: E
Condition: Used
Material: Glasslined
Capacity (Design): 2,150 L (570 gallons)
Internal Pressure: 6 bar (87 psi)
agitated jacketed reactor, Order number: 50970 Volume of pressure jacket: 331 liter Belt driven by a 5,5kW electrical motor, Motor type 3KT132SA-2, 3~/50Hz/380-660V/2.870rpm, ExdeIIBT4
Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Pfaudler
Model: RA
Condition: Used
Material: Glasslined
Capacity (Design): 7,550 L (2,000 gallons)
Internal Pressure: 6.9 bar (100 psi)
Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Lugs.
