Stainless Steel 316L Robert Sanderson Agitated Tank - IPP# 242808

Type: Tank

Manufacturer: Robert Sanderson

Condition: Used

Material: Stainless Steel 316L

Capacity (Design): 34,000 L (9,000 gallons)

Orientation: Vertical

• design pressure 0.17/3.5 bar @ -15/100 degrees C,

with 2 internal coils

Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 100 °C (212 °F). Does it have an Internal Coil?: Yes. Support: Legs.

Type: Tank

Manufacturer: Industrial Process Equipment Corp.

Model: Knock Out

Condition: Used

Material: Stainless Steel 316L

Capacity (Design): 283.9 L (75 gallons)

Orientation: Vertical

• Type: knock out pot
• Customer: Nash Kinema Vessel designed for non-lethal and non-corrosive service.

Diameter: 482.6 mm (19 in). Straight-side Length: 1,500 mm (60 in). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 204.4 °C (400 °F). Support: Base Mounted.

Type: Tank

Manufacturer: WAFAG

Condition: Used

Material: Stainless Steel 316L

Capacity (Design): 160 L (42.3 gallons)

Orientation: Horizontal

• Jacketed receiver 1/2 pipe coil jacket on bottom 1/2 of tank.

Diameter: 450 mm (17.7 in). Straight-side Length: 1,000 mm (39.6 in). Internal Pressure: 2 bar (29 psi). Internal Temperature: 200 °C (392 °F). Jacket Type: Half Pipe/Limpet. Jacket Material: Stainless Steel Other. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Vacuum: Yes.

Type: Tank

Manufacturer: Fr. Maurer Ag

Condition: Used

Material: Stainless Steel 316L

Capacity (Design): 630 L (166.4 gallons)

Orientation: Horizontal

• Jacketed receiver

Diameter: 700 mm (27.6 in). Straight-side Length: 1,600 mm (62.4 in). Internal Pressure: 2 bar (29 psi). Internal Temperature: 200 °C (392 °F). Jacket Type: Half Pipe/Limpet. Jacket Material: Stainless Steel 316L. Jacket Pressure: 4.8 bar (69.6 psi). Jacket Temperature: 200 °C (392 °F).
